凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (9-48) - MESH WRAP KIT, SHIELDS AND SLIDE ASSEMBLIES, SERIAL NUMBER CFH0073001 THROUGH CFH0073202 Case Agriculture_凯斯Case_工程机械

凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (9-48) - MESH WRAP KIT, SHIELDS AND SLIDE ASSEMBLIES, SERIAL NUMBER CFH0073001 THROUGH CFH0073202 Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 403 次

Pos.	Part No	Qty	Parts name	Comments
1.	700125851	[1]	ROLLER	HFI ASSEMBLY (Includes item 7)
2.	700710922	[1]	V-BELT,1140.46 mm L	L
3.	700125782	[1]	SUPPORT	HFI WA
4.	433-620	[2]	CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5	CAS BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
5.	231-5146	[11]	FLANGE NUT,3/8"-16	CAS Superseded by part number: 72187068, 247780
6.	121-237	[3]	SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl	CAS 3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
7.	8050825	[2]	BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm	L - cylindrical Superseded by part number: F82059
8.	61-43820	[2]	HEX SOC SCREW,FLAT, 3/8" x 1-1/4"	CAS 3/8-16 X 1-1/4 HSFCHCS Superseded by part number: 82039
9.	700714564	[36]	SCREW	CAS 5/16-18 X 1 CRFCHTCTS Superseded by part number: 166481
10.	700711967	[1]	VALVE	CAS ASSEMBLY - control
11.	700125786	[8]	SLIDE	HFI WA
12.	700122995	[4]	STRAP	HFI
13.	700125801	[1]	ROLLER	CAS ASSEMBLY (Includes item 17)
14.	413-620	[4]	BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5	CAS C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
15.	496-11041	[2]	WASHER,13/32" x 13/16" x .065", HDN	CAS 3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
16.	232-5316	[4]	FLANGE NUT,Flg, 3/8"-16	CAS 3/8-16 HFTLN GR/G Superseded by part number: 86521609
17.	586156R92	[2]	BEARING, ROLLER, CYL,0.7505" ID x 47 mm OD x 0.8437, 0.53125"	IH BEARING - cylindrical Superseded by part number: 76802
18.	700125790	[1]	SUPPORT	HFI WA
19.	413-532	[4]	BOLT,Hex, 5/16" - 18 x 2", Gr 5	CAS Superseded by part number: 9636711
20.	231-5145	[26]	SERRATED NUT,Flg, USR, 5/16"-18	CAS NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
21.	700125805	[1]	SUPPORT	HFI WA
22.	121-115	[6]	SERRATED BOLT,Hex, 5/16" - 18 x 3/4"	CAS
23.	413-536	[4]	BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5	CAS Hex, 5/16-18 X 2-1/4 C Superseded by part number: 86505972
24.	496-21034	[6]	WASHER,11/32" x 11/16" x 0.89", HDN	CAS Superseded by part number: 86637953
25.	700125793	[2]	SUPPORT	HFI WA
26.	434-616	[4]	CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5	CAS 3/8-16 X 1 RHSNB Superseded by part number: 80280503
27.	700125905	[2]	PLATE	HFI
28.	413-540	[2]	BOLT,Hex, 5/16" - 18 x 2-1/2", Gr 5	CAS Superseded by part number: 72187202, 88346
29.	700125907	[1]	PLATE	HFI
30.	700125804	[1]	SHIELD	HFI
31.	700710880	[1]	SPRING	CAS - leaf
32.	703769	[2]	SCREW	CAS 5/16-18 X 2-3/4 C
33.	433-512	[6]	CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5	CAS Superseded by part number: 280327
34.	433-612	[2]	CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5	CAS Superseded by part number: 280430
