| 1. |
61-33832
|
[1] |
HEX SOC SCREW,3/8 - 16 x 2"
|
CAS
3/8-16 X 2 HSHCS SPL
|
| 2. |
231-4116
|
[1] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 3. |
219-93
|
[1] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 4. |
700116177
|
[1] |
SUPPORT
|
HFI
(Includes item 6)
|
| 5. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 6. |
740514
|
[2] |
BUSHING,31.81mm ID x 38.2mm OD x 50.8mm L
|
L
- oilite
|
| 7. |
409-7820
|
[4] |
BOLT,Hex Flg, 1/2" - 13 x 1 1/4", Spcl
|
CAS
Superseded by part number: 84209
|
| 8. |
6551394
|
[4] |
SHIM
|
HFI
|
| 9. |
433-512
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 10. |
700125069
|
[2] |
SPACER
|
HFI
|
| 11. |
700709190
|
[1] |
GEARBOX ASSY
|
CAS
GEARBOX
|
| 12. |
444030
|
[1] |
REDUCER,1/2"-14 NPTF x 1/8"-27 Fem NPTF
|
IH
BUSHING - reducer
|
| 13. |
152127H1
|
[1] |
BREATHER,1/8"-27, Short
|
IH
- vent Superseded by part number: 219-433
|
| 14. |
700119133
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - pump
|
| 15. |
111-622
|
[1] |
CARRIAGE BOLT,Short NK 5/8" -11 x 2 1/4", G5
|
CAS
5/8-11 X 2-1/4 RHSNB
|
| 16. |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 17. |
425-1010
|
[1] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 18. |
700119717
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - sensor
|
| 19. |
700117086
|
[1] |
STRAP
|
HFI
|
| 20. |
413-824
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 21. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 22. |
705541
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 23. |
700116094
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - switch
|
| 24. |
700118822
|
[1] |
SPACER
|
CAS
|
| 25. |
52175
|
[1] |
BUSHING,25.48mm ID x 38.2mm OD x 3.17mm L
|
CAS
5/8 X 18 GAUGE NRMB
|
| 26. |
700708998
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - 40B17 tooth
|
| 27. |
114-102
|
[1] |
BOLT,Hex, 5/16" - 24 x 3/4", Gr 5
|
CAS
Superseded by part number: 280559
|
| 28. |
492-11031
|
[1] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 29. |
495-61034
|
[2] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 30. |
700708338
|
[1] |
LINK
|
CAS
#40 CONNECTOR LINK
|
| 31. |
700707710
|
[1] |
CHAIN (AG)
|
CAS
#40 CHAIN - roller, O-Ring
|
| 32. |
47977
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - idler, 18 tooth Superseded by part number: 103243
|
| 33. |
413-412
|
[2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5
|
CAS
Superseded by part number: 9707580, 72187189
|
| 34. |
231-5144
|
[2] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 35. |
700707234
|
[1] |
BUTTON
|
IH
KNOB
|
| 36. |
700125103
|
[1] |
PLATE
|
HFI
|
| 37. |
700125072
|
[1] |
PLATE
|
HFI
WA
|
| 38. |
61-832
|
[2] |
HEX SOC SCREW,1/2"-13 x 2"
|
CAS
1/2-13 X 2 HSHCS SPL Superseded by part number: 86570628
|
