凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (2-08) - GEARBOX ASSEMBLY, 700709190 GEARBOX ASSEMBLY COMPLETE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
295 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700709190
|
[1] |
GEARBOX ASSY
|
CAS
GEARBOX ASSEMBLY - complete
|
| 1. |
700712180
|
[2] |
RING, SNAP
|
CAS
RING - retaining
|
| 2. |
700712179
|
[2] |
SHAFT
|
CAS
|
| 3. |
700709400
|
[2] |
SHAFT
|
CAS
(Superseded by 700712179 and 700712180) Superseded by part number: 700712180, 700712179
|
| 4. |
H755694
|
[2] |
SEAL ASSY.
|
CAS
SEAL - oil
|
| 5. |
700709192
|
[2] |
CAP
|
CAS
ASSEMBLY (Includes items 4 and 9)
|
| 6. |
806950
|
[2] |
GASKET
|
IH
- shim (.003)
|
| 7. |
806943
|
[2] |
GASKET
|
IH
- shim (.005)
|
| 8. |
806935
|
[2] |
GASKET
|
IH
- shim (.015)
|
| 9. |
131312C1
|
[2] |
BEARING CUP
|
IH
BEARING - cup Superseded by part number: 73124678
|
| 10. |
871244R1
|
[2] |
ROLLER BEARING
|
IH
BEARING - cone Superseded by part number: 73124678
|
| 11. |
700711939
|
[1] |
GEAR
|
CAS
|
| 12. |
700711935
|
[1] |
SHIM
|
CAS
- (.010)
|
| 13. |
700711936
|
[1] |
SHIM
|
CAS
- (.005)
|
| 14. |
800334
|
[2] |
ROLLER BEARING,29.38 mm ID x 25.433 mm
|
HFI
BEARING - cone
|
| 15. |
13447D
|
[2] |
BEARING
|
IH
CUP - bearing Superseded by part number: 86900791
|
| 16. |
700709419
|
[2] |
WASHER
|
CAS
- special
|
| 17. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 18. |
800268
|
[1] |
SHIM
|
CAS
- (.002)
|
| 19. |
700709193
|
[2] |
KEY
|
CAS
- special
|
| 20. |
800417
|
[16] |
SCREW
|
CAS
3/8-16 X 1-1/4 C
|
| 21. |
800359
|
[1] |
GEAR
|
CAS
|
| 22. |
700709191
|
[1] |
BOX
|
CAS
HOUSING ASSEMBLY (Includes item 15)
|
