| 1. |
Q3914
|
[1] |
KEY,Gib, 1/4" Sq x 1 1/2"
|
IH
1/4 X 1-1/2 GIB KEY
|
| 2. |
700109639
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET 50B35 TOOTH
|
| 3. |
700126798
|
[1] |
ROTOR
|
HFI
WA
|
| 4. |
434-616
|
[35] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 5. |
492-11038
|
[9] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 6. |
425-106
|
[6] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 7. |
413-620
|
[3] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 8. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
- bearing
|
| 9. |
51292
|
[2] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
Superseded by part number: 84330041, 47508357
|
| 10. |
413-616
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 11. |
700705612
|
[4] |
CAM FOLLOWER
|
L
BEARING - cam, follower Superseded by part number: 86536275
|
| 12. |
702700045
|
[4] |
LOCK NUT
|
L
1/2-20 SPIRALOCK
|
| 13. |
700108618
|
[4] |
ARM
|
L
CRANK WA
|
| 14. |
710392
|
[8] |
BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm
|
L
BEARING - cylindrical Superseded by part number: 84330047
|
| 15. |
61-33836
|
[4] |
HEX SOC SCREW,3/8 - 16 x 2-1/4"
|
CAS
3/8-16 X 2-1/4 HSHCS SPL
|
| 16. |
232-5316
|
[52] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 17. |
433-620
|
[16] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 18. |
700125083
|
[4] |
STRAP
|
HFI
|
| 19. |
700119965
|
[4] |
ANGLE BAR
|
L
ANGLE WA
|
| 20. |
700709760
|
[48] |
TINE
|
L
TINE - double
|
| 21. |
432-1632
|
[8] |
COTTER PIN,1/4" x 2"
|
CAS
Pin, Split (Cotter), 1/4" x 2" Superseded by part number: 88182
|
| 22. |
700108622
|
[8] |
FLANGED BEARING
|
L
FLANGE - bearing
|
