沃尔沃零件查询A25 VOLVO BM Retarder with fitting parts 91015VOLVO BM A25 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
541 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
VOE1598173
|
[1] |
Accelerator pedal
|
|
| 2. |
VOE324714
|
[1] |
Attaching bracket
|
|
| |
VOE1588548
|
[1] |
Bushing
|
|
| 3. |
VOE191240
|
[1] |
Bolt
|
|
| 4. |
VOE13907860
|
[1] |
Cotter Pin
|
|
| 5. |
VOE13946934
|
[1] |
Screw
|
|
| 6. |
VOE13945407
|
[1] |
Nut
|
|
| 7. |
VOE1502073
|
[1] |
Contact
|
Cab - 5860
|
| |
VOE1589502
|
[1] |
Foot operated switch
|
Cab 5861 -
|
| 8. |
VOE11053684
|
[1] |
Water pipe
|
|
| 9. |
VOE11032686
|
[1] |
Connecting pipe
|
|
| 10. |
VOE943478
|
[4] |
Hose clamp
|
|
| 11. |
VOE11053789
|
[1] |
Pipe
|
|
| 12. |
VOE949478
|
[REQ] |
Hose
|
L=2000
|
| 13. |
VOE11104606
|
[3] |
Retaining strap
|
|
| 14. |
VOE13945734
|
[1] |
Clamp
|
|
| 15. |
VOE11053075
|
[1] |
T-pipe
|
|
| 16. |
VOE943479
|
[1] |
Hose clamp
|
|
| 17. |
VOE943371
|
[REQ] |
Hose
|
L=50
|
| 18. |
VOE11043087
|
[1] |
Temperature sensor
|
|
| 19. |
VOE13945653
|
[1] |
Plane gasket
|
|
| 20. |
VOE11043086
|
[1] |
Reducing valve
|
|
| 21. |
VOE13945444
|
[2] |
Screw
|
|
| 22. |
VOE11053134
|
[1] |
Anchorage
|
|
| 23. |
VOE955306
|
[2] |
Hexagon screw
|
|
| 24. |
VOE930840
|
[4] |
Plain washer
|
|
| 25. |
VOE946036
|
[4] |
Lock nut
|
|
| 26. |
VOE11701327
|
[1] |
Banjo fitting
|
|
| 27. |
VOE941521
|
[2] |
Fitting nut
|
|
| 28. |
VOE13949361
|
[2] |
Sleeve
|
|
| 29. |
VOE13956967
|
[2] |
Ferrule
|
|
| 30. |
VOE930032
|
[1] |
Testing nipple
|
|
| |
VOE958225
|
[1] |
O-ring
|
|
| 31. |
VOE946940
|
[1] |
Nipple
|
|
| 32. |
VOE954356
|
[7] |
Fitting nut
|
|
| 33. |
VOE944717
|
[7] |
Sleeve
|
|
| 34. |
VOE954364
|
[7] |
Ferrule
|
|
| 35. |
VOE945916
|
[4] |
Elbow nipple
|
|
| 36. |
VOE945893
|
[4] |
Hexagon nut
|
|
| 37. |
VOE13948867
|
[2] |
Nipple
|
|
| 38. |
VOE13947627
|
[2] |
Plane gasket
|
|
| 39. |
VOE13945460
|
[REQ] |
Plastic pipe
|
L=2X1500
|
| 40. |
VOE1587176
|
[4] |
O-ring
|
|
| 41. |
VOE13945460
|
[REQ] |
Plastic pipe
|
L=1000
|
| 42. |
VOE11062740
|
[1] |
Temperature gauge
|
|
| 43. |
VOE11039094
|
[1] |
Timer relay
|
10S
|
| 44. |
VOE4786690
|
[1] |
Relay
|
|
