神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (03-008) - GOVERNOR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
123 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2-83. | VAME032813 | [1] | GOVERNOR ASSY RSV TYPE | |
| 2. | VA0908780030 | [1] | PLATE | |
| 3. | VA0908110900 | [1] | HOUSING,GOV | |
| 7. | VA0910240031 | [1] | STOPPER | |
| 7A. | VA0910240031 | [1] | STOPPER | |
| 8. | VA9480530051 | [2] | NUT,LOCK | |
| 9. | VA0902410010 | [2] | PLUG | KOB |
| 10. | VA0911670050 | [1] | PLUG | |
| 13. | VA0908400630 | [1] | FLYWEIGHT SUB ASSY | |
| 14. | VA9491300050 | [1] | KEY,WOODRUFF | |
| 15. | VA9490150500 | [1] | WASHER,SPG | |
| 16. | VA0908440010 | [1] | NUT,ROUND | |
| 17. | VA0908610010 | [1] | SLEEVE | |
| 18. | VA9491000010 | [1] | BEARING,BALL | |
| 19. | VA9490134060 | [1] | SHIM,PLATE T = 0.2 | |
| 19. | VA9490134070 | [1] | SHIM,PLATE T = 0.3 | |
| 19. | VA9490134080 | [1] | SHIM,PLATE T = 0.4 | |
| 19. | VA9490134090 | [1] | SHIM,PLATE T = 0.1 | |
| 19. | VA9490134100 | [1] | SHIM,PLATE T = 1.0 | |
| 20. | VA0908230180 | [1] | GASKET | |
| 21. | VA0910111351 | [1] | GOVERNOR COVER SUB ASSY | |
| 22. | VA0910160020 | [1] | BUSHING,BRG | |
| 23. | VA0908800110 | [1] | SWIVELING LEVER ASSY | |
| 24. | VA0908920080 | [2] | BUSHING,LEVER | |
| 26. | VA9080120160 | [2] | O-RING | |
| 27. | VA9490710090 | [2] | E-RING | |
| 28. | VA9491500210 | [1] | SEAL | KOBOIL |
| 29. | VA0909300560 | [1] | GUIDE LEVER ASSY | |
| 29. | VA9040002101 | [1] | PIN,SPLIT | |
| 30. | VA0909700170 | [1] | SHACKLE SUB ASSY | |
| 32. | VA9490180350 | [2] | WASHER,PLATE | |
| 34. | VA0909000170 | [1] | LEVER,TENSION | |
| 35. | VA0910060150 | [1] | STOPPER,FULL ROAD | |
| 36. | VA9490503390 | [1] | NUT,LOCK | |
| 37. | VA9490181020 | [2] | WASHER | KOBGASKET |
| 38. | VA0910310150 | [1] | NUT,CAP | |
| 38A. | VA0909440310 | [1] | BUSHING | |
| 388. | VA9080110120 | [1] | O-RING | |
| 39. | VA0909890010 | [1] | SHAFT,LEVER | |
| 40. | VA0909910010 | [2] | PLUG,SCREW | |
| 41. | VA0909920310 | [1] | SPRING,CONTROL | |
| 42. | VA0909930010 | [1] | SPRING,START | |
| 43-43E. | VA0909100620 | [1] | ADAPTER ASSY | |
| 43. | VA0909190010 | [1] | ADAPTER | |
| 43B. | VA0909180110 | [1] | SPRING,ADAPTER | |
| 43C. | VA9490133880 | [1] | SHIM T=0.10 | |
| 43C. | VA9490134020 | [1] | SHIM T=0.25 | |
| 43C. | VA9490134030 | [1] | SHIM T=0.50 | |
| 43C. | VA9490134040 | [1] | SHIM T=0.20 | |
| 43D. | V0909110010 | [1] | SCREW,ADAPTER | |
| 43E. | VA0908940010 | [1] | FASTENER | KOBRING,SNAP |
| 44. | VA0909230011 | [1] | NUT,ADAPTER LOCK | |
| 46. | VA0905600170 | [1] | SCREW,ADAPTER | |
| 47. | VA0909230060 | [1] | NUT,LOCK | |
| 48. | VA9480530090 | [1] | NUT | |
| 49. | VA0910310030 | [1] | NUT,CAP | |
| 50. | VA0910500410 | [1] | COVER PLATE SUB ASSY | |
| 51. | VA9490621270 | [1] | O-RING | |
| 52. | VA9490401140 | [2] | BOLT | |
| 53. | VA9141806161 | [2] | BOLT.W/WSR | |
| 54. | VA9490471760 | [4] | BOLT | |
| 56. | VA9490471750 | [2] | BOLT | |
| 57-57E. | VA0909100900 | [1] | ADAPTER ASSY | |
| 57. | VA09056712000 | [1] | WASHER,SNAP | |
| 57B. | VA0909190240 | [1] | ADAPTER | |
| 57C. | VA0909180211 | [1] | SPRING,TORQUE | |
| 57D. | VA9490133880 | [1] | SHIM,PLATE T=0.10 | |
| 57D. | VA9490134020 | [1] | SHIM,PLATE T=0.25 | |
| 57D. | VA9490134030 | [1] | SHIM,PLATE T=0.50 | |
| 57D. | VA9490134040 | [1] | SHIM,PLATE T=0.20 | |
| 57E. | VA0900260080 | [1] | SCREW,ADJUSTING | |
| 59. | VA0900320040 | [1] | CAP | |
| 62. | VA0910430010 | [1] | COVER,SPG | |
| 63. | VA9491300030 | [1] | KEY,WOODRUFF | |
| 64. | VA9490471190 | [1] | SCREW,LEVER SET | |
| 65. | VA0911700070 | [1] | LEVER SUB ASSY,TORQUE | |
| 66. | VA0910711420 | [1] | ADJUSTING LEVER SUB ASSY | |
| 67. | VA0910940060 | [1] | CAP,LEVER | |
| 68. | VA0910980082 | [1] | LEVER | KOB |
| 69. | VA9141806141 | [1] | BOLT.W/WSR | |
| 70. | VA9021808250 | [1] | WASHER,PLATE | |
| 71. | VA0910340160 | [1] | SUPPORT,LEVER | |
| 72. | VA0910350240 | [1] | SHAFT.GOV | |
| 73. | VA0910360010 | [1] | CUP,SPG | |
| 74. | VA0910380030 | [1] | SPRING,OUTER | |
| 75. | VA0910380040 | [1] | SPRING,INNER | |
| 75A. | VA0910380050 | [1] | SPRING,MIDDLE | |
| 76. | VA0910330030 | [1] | PLATE,CAP | |
| 78. | VA0910420220 | [1] | SPRING,RETURN | |
| 79. | VA9491400130 | [1] | O-RING | O-RING |
| 80. | VA0908940030 | [1] | E-RING | |
| 81. | VA0910840050 | [1] | PIN.5UPPORT | |
| 63. | VA0908230240 | [1] | GASKET | |
| 86. | VA9141806161 | [6] | SCREW | |
| 89. | VA9151808221 | [1] | BOLT, W/WSR | |
