| 1. |
218-5106
|
[1] |
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
|
CAS
- 90 degrees (Includes item 3) Superseded by part number: 72186176, 128830
|
| 2. |
214-1420
|
[2] |
HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm
|
CAS
CLAMP, HOSE, #20, 0.81/1.75 Type F Worm Superseded by part number: 507586
|
| 3. |
237-6008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk Superseded by part number: 128825
|
| 4. |
7796782
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 5. |
413-5104
|
[2] |
BOLT,Hex, 5/16" - 18 x 6-1/2", Gr 5
|
CAS
5/16-18 X 6 C Superseded by part number: 85807859
|
| 6. |
492-11031
|
[2] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 7. |
496-21034
|
[2] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 8. |
6525877
|
[3] |
CLAMP
|
HFI
STRAP
|
| 9. |
700708071
|
[1] |
RESERVOIR ASSY.
|
CAS
RESERVOIR - oil
|
| 10. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 11. |
231-5146
|
[3] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 12. |
700116124
|
[1] |
LUG
|
HFI
|
| 13. |
221-215
|
[1] |
PIPE,Nipple, 3/4" NPT x 2"
|
CAS
NIPPLE - pipe
|
| 14. |
700119134
|
[1] |
ELBOW
|
CAS
- 90 degrees
|
| 15. |
700713394
|
[1] |
TEE
|
CAS
- male run
|
| 16. |
742643
|
[1] |
FILTER
|
CAS
(Includes item 18)
|
| 17. |
218-483
|
[1] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 1/4" - 18 Male NPTF
|
CAS
- 90 degrees Superseded by part number: 578384
|
| 18. |
201021C1
|
[1] |
ELEMENT
|
IH
- filter
|
| 19. |
218-1056
|
[1] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, NPTF
|
CAS
- 90 degrees Superseded by part number: 216744
|
| 20. |
7825516
|
[1] |
FILTER
|
L
|
| 21. |
195504C2
|
[1] |
HYDRAULIC HOSE
|
IH
HOSE - hydraulic
|
| 22. |
700708076
|
[1] |
FILLER CAP
|
CAS
CAP - filler
|
| 23. |
895482
|
[1] |
HYDRAULIC HOSE,12.70 mm ID x 431.80 mm, SAE 30R2, SAE J517, SAE J516, SAE J343
|
CAS
12.70 mm ID x 431.80 mm, SAE 30R2, SAE J517, SAE J516, SAE J343
|
| 24. |
700707444
|
[1] |
VALVE
|
HFI
ASSEMBLY - automatic
|
