700707444
|
[1] |
VALVE
|
HFI
HYDRAULIC CONTROL VALVE COMPLETE
|
| 1. |
700707835
|
[1] |
PLUG
|
CAS
#4 SAE PLUG (Includes item 2)
|
| 2. |
237-6004
|
[1] |
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
|
CAS
4-1, 90 Duro, .351" ID x .072" Thk Superseded by part number: 165202, 72186131
|
| 3. |
149942C1
|
[11] |
SEAL KIT
|
IH
O-RING AND SEAL REPAIR KIT Superseded by part number: 86508168
|
| 4. |
700707831
|
[2] |
VALVE
|
L
- check
|
| 5. |
700706604
|
[1] |
PLUG
|
CAS
- 8 SAE (Includes item 6)
|
| 6. |
237-6008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk Superseded by part number: 128825
|
| 7. |
700707830
|
[1] |
VALVE, CONTROL
|
CAS
VALVE - flow control Superseded by part number: 9824326, 700709570, H757815, 700709569
|
| . . |
700121500
|
[1] |
KIT
|
HFI
VALVE - flow control, service kit (S.N. CFH0016501 thru CFH0016838)
|
| . . |
700709569
|
[1] |
VALVE
|
CAS
- flow control (Use with orifice in threader) (S.N. CFH0016839 and later)
|
| 8. |
700709818
|
[1] |
NUT
|
CAS
|
| 9. |
700709819
|
[1] |
KNOB
|
CAS
|
| 10. |
700710890
|
[1] |
PISTON
|
CAS
- wing
|
| 11. |
700706157
|
[2] |
HYDRAULIC VALVE
|
L
VALVE - relief (2000 PSI)
|
| 12. |
700706158
|
[1] |
DRAINCOCK/TAP SUPPLY
|
IH
VALVE - needle
|
| 13. |
700709384
|
[1] |
ORIFICE
|
CAS
(.02)
|
| 14. |
700707833
|
[2] |
VALVE, CHECK
|
CAS
VALVE - check, poppet (15 PSI spring)
|
| 15. |
700710891
|
[2] |
PISTON
|
CAS
- pilot
|
| 16. |
221-850
|
[4] |
PLUG,Hex Soc, 1/16"-27
|
CAS
- pipe 1/16 NPT
|
| 17. |
700707827
|
[1] |
VALVE, PRESSURE RELI
|
CAS
VALVE - relief (Knob adjustment) (Replaced with 700706157) Superseded by part number: 700706157
|
| 18. |
700706152
|
[2] |
SEAL KIT
|
CAS
O-RING AND SEAL REPAIR KIT Superseded by part number: 47394721
|
| 19. |
700706148
|
[2] |
CARTRIDGE
|
CAS
SOLENOID (2-Pos., 3-Way)
|
| 20. |
700706151
|
[5] |
NUT
|
CAS
HEX NUT Superseded by part number: 87033382
|
| 21. |
700707832
|
[2] |
VALVE PRESSURE RELIE
|
CAS
VALVE - check, ball (5 PSI spring)
|
| 22. |
700707829
|
[1] |
VALVE, PRESSURE RELI
|
HFI
VALVE - relief, knob Adj. (2000 PSI)
|
| 23. |
700707215
|
[3] |
SEAL KIT
|
IH
O-RING AND SEAL REPAIR KIT
|
| 24. |
700706610
|
[3] |
CARTRIDGE
|
L
SOLENOID (2-Pos., 4-Way)
|
| 25. |
700707825
|
[5] |
COIL
|
IH
(10V DC)
|
| . . |
700710176
|
[5] |
COIL
|
CAS
(12V DC)
|
| 26. |
218-5151
|
[5] |
PLUG,Hex Hd, 5/16"-24 ORB
|
CAS
(#2 SAE) (Includes item 27)
|
| 27. |
238-5010
|
[5] |
O-RING,0.07" Thk x 0.239" ID, -10, Cl 5, 75 Duro
|
CAS
-010, 70 Duro, .239" ID x .070" Thk Superseded by part number: 49886
|
| 28. |
700707826
|
[5] |
REPAIR KIT
|
CAS
KIT - coil housing
|
