神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (03-011) - FUEL FEED PUMP (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
771 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-24. | VAME0328140 | [1] | FUEL FEED PUMP ASSY KE TYPE | |
| 1. | VA0921260010 | [1] | PLUG,CHAMBER | |
| 2. | VA0902220070 | [4] | WASHER | KOBSEAL Superseded by part number: VA0594601401 |
| 4. | VA0921250010 | [2] | GASKET | KOBPLUG |
| 5. | VA0921240010 | [2] | SPRING | KOBCHECK/V |
| 6. | VA0921210011 | [2] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE CHECK |
| 7-8. | VA0921200171 | [1] | HOUSING SUB ASSY | |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING |
| 8. | VA0921680010 | [1] | PUSH ROD BLUE | |
| 8. | VA0921680030 | [1] | PUSH ROD RED | |
| 8. | VA0921680040 | [1] | PUSH ROD YELLOW | |
| 8. | VA0921680050 | [1] | PUSH ROD GREEN | |
| 8. | VA0921680060 | [1] | PUSH ROD WHITE | |
| 8. | VA0921680070 | [1] | PUSH ROD BROWN | |
| 9. | VA0921840021 | [1] | PLUG,PISTON CHAMBER | |
| 10. | VA9490181240 | [1] | WASHER | WASHER |
| 11. | VA9218200201 | [1] | SPRING,PISTON | |
| 12. | VA0921710010 | [1] | MANIFOLD PISTON BLUE | MANIFOLD PISTON BLUE |
| 12. | VA0921710020 | [1] | PISTON RED | |
| 12. | VA0921710030 | [1] | PISTON YELLOW | |
| 12. | VA0921710040 | [1] | PISTON GREEN | |
| 12. | VA0921710050 | [1] | PISTON WHITE | |
| 15. | VA9222000400 | [1] | FILTER,FUEL | |
| 16. | VA9222300070 | [1] | SCREW | |
| 16A. | VA9491800310 | [1] | JACK SCREW | KOBSCREW |
| 17. | VA0921300220 | [1] | ENGINE OIL PUMP | KOBPRIMING Superseded by part number: VA3446129516 |
| 18. | VA9490720940 | [1] | RING,SNAP | |
| 20. | VA0921760010 | [1] | ROLLER,TAPPET | |
| 21. | VA0921740030 | [1] | TAPPET | |
| 22. | VA0921780010 | [1] | PIN,ROLLER | |
| 23. | VA0921790050 | [2] | BLOCK,SLIDING | |
| 24. | VA9491810160 | [1] | NIPPLE,SWIVELING D = 8 | |
