神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (03-016) - FUEL INJECTION PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
832 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME047092 | [1] | PIPE,INJECTION N0.1 | |
| 2. | VAME047093 | [1] | PIPE,INJECTION NO.2 | |
| 3. | VAME047094 | [1] | PIPE,INJECTION NO.3 | |
| 4. | VAME047095 | [1] | PIPE,INJECTION NO.4 | |
| 5. | VAME047096 | [1] | PIPE,INJECTION NO.5 | |
| 6. | VAME047097 | [1] | PIPE,INJECTION NO.6 | |
| 7. | VAMH020258 | [5] | CLAMP | KOBCLAMP Superseded by part number: 134717A1 |
| 8. | VAMH020259 | [1] | CLAMP | KOBCLAMP Superseded by part number: 134718A1 |
| 9. | VAMH020260 | [1] | CLAMP | KOBCLAMP |
| 10. | VAMH021252 | [1] | CLAMP | KOBCLAMP |
| 11. | VAMF240029 | [3] | SCREW | KOBBOLT,W/WSR 6X25 |
| 12. | VAMF434103 | [2] | NUT | KOBNUT,FLANGE 6 |
