| 1-12. | VAME036780 | [6] | NOZZLE | KOBNOZZLE ASSY 220KG/CM2,FOR M0 ONLY |
| 1-12. | VAME035803 | [6] | NOZZLE | KOBNOZZLE ASSY 220KG/CM2,FOR M2 ONLY |
| 1-11. | VAME036561 | [6] | NOZZLE HOLDER ASSY | |
| 1. | VAME705400 | [6] | SCREW | KOBBOLT,EYE Superseded by part number: 77270082, 134650A1 |
| 2. | VAME705389 | [12] | PACKING | KOBGASKET Superseded by part number: 134686A1 |
| 3. | VAME705403 | [6] | NUT | KOBNUT,CAP |
| 4. | VAME705408 | [6] | SCREW | KOBSCREW,ADJUSTING |
| 5. | VAME705405 | [6] | SPRING SPRING,NOZZLE | SPRING SPRING,NOZZLE |
| 6. | VAME705406 | [6] | PUSH ROD | KOBROD,PUSH Superseded by part number: 134708A1 |
| 7. | VAME705391 | [6] | GASKET | KOBGASKET Superseded by part number: 134652A1 |
| 8. | NSS | [6] | NOT SOLD SEPARAT | CONBODY,NOZZLE HOLDER |
| 8A. | VAME705407 | [12] | PIN | KOBPIN Superseded by part number: 77270085, 134711A1 |
| 9. | VAME705401 | [6] | HYD CONNECTOR | KOBCONNECTOR,INLET |
| 10. | VAME705390 | [6] | GASKET | KOBGASKET Superseded by part number: VA0293005070 |
| 11. | VAME705402 | [6] | NUT | KOBNUT,RETAINING |
| 12. | VAME036781 | [6] | NOZZLE | KOBTIP,NOZZLE 0.29-5,FOR M0 ONLY |
| 12. | VAME035806 | [6] | TIP,NOZZLE TIP,NOZZLE 0.32-4,FOR M2 ONLY | TIP,NOZZLE TIP,NOZZLE 0.32-4,FOR M2 ONLY |
| 13. | VAME036562 | [6] | DUST CAP | KOBSEAL,DUST |
| 14. | VA3096102300 | [6] | O-RING | KOBGASKET,NOZZLE TIP |
| 15. | VAMH000656 | [12] | SET SCREW | KOBBOLT,NOZZLE HOLDER |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CONND,FOR M0 ONLY |
| 1-12. | VAME036748 | [6] | NOZZLE | KOBNOZZLE ASSY,FOR M0 ONLY |
| 1-11. | VAME036571 | [6] | NOZZLE HOLDER ASSY,FOR M0 ONLY | |
| 1. | VA9491800152 | [6] | SCREW,HOLLOW,FOR M0 ONLY | |
| 2. | VA9490181020 | [6] | WASHER | KOBWASHER,NIPPLE,FOR M0 ONLY |
| 3. | VA0931340290 | [6] | NUT | KOBNUT,CAP,FOR M0 ONLY |
| 4. | VA0931310200 | [6] | SCREW,ADJUSTING,FOR M0 ONLY | |
| 5. | VA0931270270 | [6] | SPRING,PRESS,FOR M0 ONLY | |
| 6. | VA0931210330 | [6] | PIN,PRESS,FOR M0 ONLY | |
| 7. | VA0932450052 | [6] | WASHER,FOR M0 ONLY | |
| 9. | VA0931510280 | [6] | CONNECTOR,INLET,FOR M0 ONLY | |
| 10. | VA0931580010 | [6] | GASKET,FOR M0 ONLY | |
| 11. | VA0931640781 | [6] | NUT,RETAINNING,FOR M0 ONLY | |
| 12. | VAME036749 | [6] | NOZZLE | KOBTIP,NOZZLE 0.29-5,FOR M0 ONLY |
