神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (01-001) - CYLINDER BLOCK Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
196 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCRANKCASE |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONCAP, BRG, FR & MI |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG, RE |
| 4. | VAME031865 | [14] | SCREW | KOBMAIN CAP 14 X 108 |
| 5. | VAME071063 | [1] | LINER, ENGINE CYLIND | KOBCYL ME071062 |
| . . | VAME071064 | [6] | LINER, ENGINE CYLIND | KOB |
| . . | VAME071065 | [1] | SIZE C | |
| 6. | VAME031610 | [12] | O-RING | KOB |
| 7. | VAME071066 | [6] | PACKING | KOB |
| 8. | VAMH012041 | [6] | PIN | KOBPIN, SPG 4 X 10 |
| 9. | VAMH037137 | [2] | PLUG | KOBPLUG 20 |
| . . | VAMF660068 | [2] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 11. | VAMH012024 | [2] | PIN | KOBPIN, SPG 10 X 20 |
| 12. | VAMH007011 | [1] | PIN | KOBPIN, DOWEL 12 X 34 Superseded by part number: 132324A1 |
| 13. | VAMF665535 | [1] | CAP | KOBCAP, SEALING 18 |
| 14. | VAMH007010 | [1] | PIN | KOBPIN, DOWEL 12 X 17 |
| 15. | VAMF472404 | [2] | DOWEL | KOBPIN, DOWEL 8 X 18 Superseded by part number: MF472404 |
| 16. | VAMH037082 | [2] | PLUG PLUG 6.5 X 8 | PLUG PLUG 6.5 X 8 |
| 17. | VAME071141 | [1] | BUSHING | KOBME071078 |
| 18. | VAME071142 | [1] | BUSHING | KOBME071079 |
| 19. | VAME071143 | [1] | BUSHING | KOBME071080 |
| 20. | VAME071144 | [1] | BUSHING | KOBME071081 Superseded by part number: VAME071862 |
| 21. | VAME031087 | [1] | SET OF SCREWS | KOB |
| . . | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 22. | VAMH000713 | [5] | BOLT | KOBBOLT, FLANGE 10 X 20 |
| 23. | VAME031048 | [1] | COVER FR | COVER FR |
| 24. | VAME031049 | [1] | GASKET | KOBFR COVER Superseded by part number: VAME071268, 77269045 |
| 26. | VAME071269 | [1] | OIL SEAL | KOBFR, M9 ONLY |
| . . | VAME031543 | [1] | OIL SEAL | KOBM6 ONLY |
| 27. | VAMH000843 | [5] | SCREW | KOBBOLT, FLANGE 12 x 25 Superseded by part number: 132385A1 |
| 30. | VAMH037763 | [6] | PLUG PLUG, M6 ONLY | PLUG PLUG, M6 ONLY |
| 31. | VAME071069 | [6] | BODY | KOBM9 ONLY |
| 32. | VAME031518 | [6] | VALVE CHECK, M9 ONLY | VALVE CHECK, M9 ONLY |
| 33. | VAME031086 | [6] | WASHER | KOBLOCK, M9 ONLY |
| 35. | VAME030823 | [1] | SHIM | KOBT=0.05 |
| . . | VAME030824 | [1] | SHIM | KOBT=0.10 |
