神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (01-002) - CYLINDER BLOCK Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
167 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCRANKCASE |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONCAP, BRG, FR & MI |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG, RE |
| 4. | VAME031865 | [14] | SCREW | KOBMAIN CAP 14 X 108 |
| 5. | VAME041102 | [1] | LINER, ENGINE CYLIND | KOBCYL A SIZE 1 ME041121 |
| . . | VAME041103 | [1] | LINER, ENGINE CYLIND | KOBA SIZE 2 |
| . . | VAME041104 | [1] | LINER, ENGINE CYLIND | KOBA SIZE 3 |
| . . | VAME041105 | [1] | LINER, ENGINE CYLIND | KOBB SIZE 1 |
| . . | VAME041106 | [6] | LINER, ENGINE CYLIND | KOBB SIZE 2 |
| . . | VAME041107 | [1] | LINER, ENGINE CYLIND | KOBB SIZE 3 |
| 8. | VAMH012041 | [6] | PIN | KOBPIN, SPG 4 X 10 |
| 9. | VAMH037137 | [2] | PLUG | KOBPLUG 20 |
| . . | VAMF660068 | [2] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 10A. | VAME041108 | [5] | CAP | KOBSEARING 50 |
| 10B. | VAMH037754 | [1] | CAP | KOBCAP, SEARING 50 |
| 10C. | VAMS666139 | [9] | CAP | KOBCAP, SEARING 30 |
| 10D. | VAMS666142 | [1] | CAP | KOBCAP, SEARING 45 |
| 11. | VAMH012024 | [2] | PIN | KOBPIN, SPG 10 X 20 |
| 12. | VAMH007011 | [1] | PIN | KOBPIN, DOWEL 12 X 34 Superseded by part number: 132324A1 |
| 13. | VAMF665535 | [1] | CAP | KOBCAP, SEALING 18 |
| 14. | VAMH007010 | [1] | PIN | KOBPIN, DOWEL 12 X 17 |
| 15. | VAMF472404 | [2] | DOWEL | KOBPIN, DOWEL 8 X 18 Superseded by part number: MF472404 |
| 16. | VAMH037082 | [2] | PLUG PLUG 6.5 X 8 | PLUG PLUG 6.5 X 8 |
| 17. | VAME071141 | [1] | BUSHING | KOBME071078 |
| 18. | VAME071142 | [1] | BUSHING | KOBME071079 |
| 19. | VAME071143 | [1] | BUSHING | KOBME071080 |
| 20. | VAME071144 | [1] | BUSHING | KOBME071081 Superseded by part number: VAME071862 |
| 21. | VAME031087 | [1] | SET OF SCREWS | KOB |
| . . | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 22. | VAMH000713 | [5] | BOLT | KOBBOLT, FLANGE 10 X 20 |
| 23. | VAME031048 | [1] | COVER FR | COVER FR |
| 24. | VAME031049 | [1] | GASKET | KOBFR COVER Superseded by part number: VAME071268, 77269045 |
| 26. | VAME071269 | [1] | OIL SEAL | KOBFR |
| 27. | VAMH000843 | [5] | SCREW | KOBBOLT, FLANGE 12 X 25 Superseded by part number: 132385A1 |
| 31. | VAME071069 | [6] | BODY | KOB |
| 32. | VAME031518 | [6] | VALVE CHECK | VALVE CHECK |
| 33. | VAME031086 | [6] | WASHER | KOBLOCK |
