神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (01-014) - CONNECTING ROD & BEARING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
719 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-5. | VAME072119 | [6] | CONNECTING ROD | KOBM0 & M2 ONLY |
| . . | VAME072120 | [6] | CONNECTING ROD | KOBM5 ONLY |
| 1. | NSS | [6] | NOT SOLD SEPARAT | CONROD, CONNECTING |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONCAP, CONN-ROD |
| 3. | VAME032553 | [12] | SCREW | KOB |
| 4. | VAME032042 | [12] | NUT | KOB Superseded by part number: 132467A1 |
| 5. | VAME072126 | [6] | BUSHING | KOBCONN-ROD M0 & M2 ONLY |
| . . | VAME072128 | [6] | BUSHING | KOBM5 ONLY |
| 6-7. | VAME999892 | [1] | SET OF STD MAIN BRGS | KOBONE MODEL STD M0 ONLY Superseded by part number: VAME997367 |
| . . | VAME999891 | [1] | METAL SET STD C/ROD M2 ONLY | METAL SET STD C/ROD M2 ONLY |
| . . | VAME999892 | [1] | SET OF STD MAIN BRGS | KOBM5 ONLY Superseded by part number: VAME997367 |
| . . | VAME999894 | [1] | SET | KOBUS Superseded by part number: VAME997368 |
| . . | VAME999893 | [1] | BEARING | KOBUS Superseded by part number: VAME997368 |
| . . | VAME999896 | [1] | SET | KOBUS 0.50 |
| . . | VAME999895 | [1] | METAL SET US 0.50 | METAL SET US 0.50 |
| . . | VAME999898 | [1] | CONN-ROD, BEARING, US 0.75 | |
| . . | VAME999897 | [1] | METAL SET 075 C/ROD US 0.75 | METAL SET 075 C/ROD US 0.75 |
| . . | VAME999900 | [1] | MAIN BEARING SET US 1.00 | MAIN BEARING SET US 1.00 |
| . . | VAME999899 | [1] | METAL SET 100 C/ROD US | METAL SET 100 C/ROD US |
| 6. | NSS | [6] | NOT SOLD SEPARAT | CONBEARING, CONN-ROD UPPER STD, ME072129, M0 ONLY |
| . . | NSS | [6] | NOT SOLD SEPARAT | CONSTD, ME072134, M2 ONLY |
| 7. | NSS | [6] | NOT SOLD SEPARAT | CONBEARING, CONN-ROD LOWER, STD, ME032417 |
