| 1. |
703249
|
[5] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| 2. |
705038
|
[12] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 3. |
704023
|
[16] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 4. |
296608
|
[2] |
BOLT,3/8" - 16 x 2"
|
CAS
-EYE
|
| 5. |
700125909
|
[1] |
SUPPORT
|
HFI
WA-LEFT
|
| 6. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 7. |
700124565
|
[1] |
SHAFT
|
HFI
WA
|
| 8. |
62083
|
[1] |
PIN
|
CAS
1/8 X 1 COTTER PIN Superseded by part number: 432-816, 432-816, NLS
|
| 9. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 HARDENED PLAIN WASHER
|
| 10. |
7770159
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 1/4" - 20 x 3/4", Gr 5
|
CAS
1/4-20 X 3/4 RHSNB Superseded by part number: 280638
|
| 11. |
523282
|
[5] |
SERRATED NUT,Flg, USR, 1/4"-20
|
WIN
1/4-20 HFSLN GR/F
|
| 12. |
700119161
|
[1] |
SWITCH
|
L
ASSEMBLY
|
| 13. |
7773849
|
[1] |
BOLT,Hex, 1/4" - 20 x 2 1/4", Gr 5
|
HFI
1/4-20 X 2-1/4 C Superseded by part number: 87405
|
| 14. |
700125910
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT-SWITCH
|
| 15. |
700124563
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING WA
|
| 16. |
20948R1
|
[1] |
PIN,1/8" x 5/8", Coiled
|
IH
1/8" x 5/8", Slotted
|
| 17. |
701888
|
[1] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 5
|
CAS
3/8-16 X 2-1/4 C Superseded by part number: 87791064, 87791064, 87936
|
| 18. |
700710211
|
[1] |
ACTUATOR
|
IH
|
| 19. |
700709603
|
[5] |
WASHER,3/8"
|
CAS
3/8 WIDE PLAIN WASHER Superseded by part number: 80702
|
| 20. |
700013
|
[6] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
51/6-18 X 3/4 RHSNB
|
| 21. |
705020
|
[6] |
LOCK WASHER
|
CAS
5/16" Superseded by part number: 492-11031, 492-11031, NLS
|
| 22. |
704015
|
[6] |
NUT,5/16"-18, G5
|
CAS
5/16-18 H Superseded by part number: 425-105, 425-105, 9635082
|
| 23. |
700125720
|
[2] |
PLATE
|
HFI
|
| 24. |
51200380
|
[4] |
FLANGE
|
CAS
|
| 25. |
50302
|
[2] |
SPHERICAL BEARING,25.4 mm ID x 52 mm OD x 30.96 mm
|
CAS
Superseded by part number: 204807C91, 47577183
|
| 26. |
700125828
|
[1] |
SUPPORT
|
HFI
WA-BRAKE
|
| 27. |
702928
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 3/4", Gr 5
|
CAS
3/8-16 X 2-3/4 C
|
| 28. |
231-4116
|
[1] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 29. |
700711167
|
[2] |
SCREW
|
CAS
1/4-20 X 3/4 CRPHMS GR 2 Superseded by part number: 86511932
|
| 30. |
700710930
|
[1] |
PAD
|
CAS
-BRAKE
|
| 31. |
58107
|
[1] |
SPRING
|
IH
-COMPRESSION
|
| 32. |
700109003
|
[1] |
BUSHING
|
CAS
|
| 33. |
61077
|
[2] |
KEY
|
CAS
1/4 X 1-1/4 KEY Superseded by part number: T13450
|
| 34. |
700125721
|
[1] |
SUPPORT
|
HFI
WA-RIGHT
|
| 35. |
7758915
|
[1] |
SPRING
|
CAS
-EXTENSION
|
| 36. |
700047
|
[4] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 37. |
768036
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/2", Gr 5
|
CAS
3/8-16 X 1-1/2 RHSNB Superseded by part number: 9706752
|
