| 1. |
700710922
|
[1] |
V-BELT,1140.46 mm L
|
L
|
| 2. |
700125851
|
[1] |
ROLLER
|
HFI
ASM (Includes Item 7)
|
| 3. |
700125782
|
[1] |
SUPPORT
|
HFI
WA
|
| 4. |
700054
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 X 1-1/4 RHSNB Superseded by part number: 86508773
|
| 5. |
704247
|
[11] |
NUT
|
CAS
3/8-16 HFSLN GR/F Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| 6. |
7883408
|
[3] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 8
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 7. |
8050825
|
[2] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
Superseded by part number: F82059
|
| 8. |
771808
|
[2] |
HEX SOC SCREW,Flat Hd, 3/8" - 16 x 1 1/4"
|
CAS
3/8-16 X 1-1/4 HSFCHCS Superseded by part number: 61-43820
|
| 9. |
51219667
|
[36] |
5/16-18 X 3/4 HSFCHCS
|
LINK BLOCK
|
| 10. |
700711967
|
[1] |
VALVE
|
CAS
-CONTROL
|
| 11. |
700125786
|
[8] |
SLIDE
|
HFI
WA
|
| 12. |
700122995
|
[4] |
STRAP
|
HFI
|
| 13. |
700125801
|
[1] |
ROLLER
|
CAS
ASM (Includes Item 17)
|
| 14. |
702035
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 X 1-1/4 C
|
| 16. |
704734
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 17. |
586156R92
|
[2] |
BEARING, ROLLER, CYL,0.7505" ID x 47 mm OD x 0.8437, 0.53125"
|
IH
BEARING Superseded by part number: 76802
|
| 18. |
700125790
|
[1] |
SUPPORT
|
HFI
WA
|
| 19. |
7703507
|
[4] |
DECAL,Hex, 5/16" - 18 x 2", Gr 5
|
CAS
5/16-18 X 2 C Superseded by part number: 413-532, 413-532, NLS
|
| 20. |
704239
|
[20] |
FRONT AXLE
|
NNA
5/16-18 HFSLN GR/F Superseded by part number: 231-5145, 231-5145, NLS
|
| 21. |
700125805
|
[1] |
SUPPORT
|
HFI
WA
|
| 22. |
7883325
|
[6] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 X 3/4 HWHMS Superseded by part number: 121-115
|
| 23. |
7771744
|
[4] |
BOLT,Hex, 5/16" - 18 x 2 1/4", Gr 5
|
CAS
5/16-18 X 2-1/4 C Superseded by part number: 86505972
|
| 24. |
705525
|
[6] |
WASHER
|
CAS
5/16 HARDENED PLAIN WASHER Superseded by part number: 86637953
|
| 25. |
700125793
|
[2] |
SUPPORT
|
HFI
WA
|
| 26. |
700047
|
[4] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 27. |
700125905
|
[2] |
PLATE
|
HFI
|
| 28. |
7703945
|
[4] |
BOLT,Hex, 5/16" - 18 x 2 1/2", Gr 5
|
CAS
5/16-18 X 2-1/2 C Superseded by part number: 88346
|
| 29. |
700125907
|
[1] |
PLATE
|
HFI
|
| 30. |
700125804
|
[1] |
SHIELD
|
HFI
|
| 31. |
700710880
|
[1] |
SPRING
|
CAS
-LEAF
|
| 32. |
7700065
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
