神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (02-002) - WATER PUMP Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
848 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-13. | VAME047422 | [1] | WATER PUMP | KOB Superseded by part number: VAME996794 |
| 1. | VAME047423 | [1] | CASE, WATER PUMP | |
| 1A. | VAME047424 | [1] | COVER | KOB |
| 2-6,15. | VAME997158 | [1] | WATER PUMP | KOB Superseded by part number: VAME996126 |
| 2. | VAMH034026 | [1] | SEAL | KOBSEAL, UNIT |
| 2A. | VAME047425 | [1] | GASKET | KOBPACKING Superseded by part number: VAME078676 |
| 3. | VAME047426 | [1] | IMPELLER | KOB |
| 4. | VAME047427 | [1] | SHAFT | KOB |
| 5. | VAMS556185 | [1] | BEARING | KOBBEARING, BALL, 6305Z Superseded by part number: VAF801206305 |
| 6. | VAMS556065 | [1] | BEARING | KOBBEARING, BALL, 6205Z |
| 7. | VA3114502900 | [1] | WASHER | KOB |
| 8. | VAME037876 | [1] | FLANGE | KOB |
| 9. | VAME920030 | [1] | SPACER | KOB |
| 10. | VAMF522236 | [1] | SNAP RING | KOBRING, SNAP 62 |
| 13. | VAMF524002 | [1] | LUBE NIPPLE | KOBNIPPLE, GREASE, PT1/8 |
| 14. | VAME039577 | [1] | PULLEY | KOBPCD155, M7 ONLY |
| . . | VAME047299 | [1] | PULLEY | KOBPCD155, M8 ONLY |
| 15. | VAME035016 | [1] | GASKET | KOB Superseded by part number: VAME075273 |
| 16. | VAMF140234 | [6] | SPECIAL BOLT | KOBBOLT, FLANGE, 8 X 45 |
| . . | VAMF140240 | [1] | BOLT | KOBBOLT, FLANGE, 8 X 75 |
| 21. | VAME035255 | [1] | HOSE | KOBBY-PASS |
| 22. | VAMS666013 | [2] | CLAMP | KOBCLAMP, HOSE 38 |
