| 1. |
700125703
|
[1] |
PANEL
|
HFI
WA - left Superseded by part number: 700124962
|
| 2. |
700125821
|
[1] |
SUPPORT
|
HFI
WA - left
|
| 3. |
413-616
|
[12] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 4. |
492-11038
|
[12] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 5. |
425-106
|
[12] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 6. |
700125812
|
[1] |
BUMPER
|
HFI
|
| 7. |
433-512
|
[11] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 8. |
492-11031
|
[13] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 9. |
425-105
|
[11] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 10. |
496-21034
|
[18] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 11. |
7758915
|
[2] |
SPRING
|
CAS
|
| 12. |
700125816
|
[1] |
FLAP
|
HFI
|
| 13. |
700125817
|
[1] |
SUPPORT
|
HFI
WA
|
| 14. |
281-14816
|
[2] |
SELF-TAP SCREW,HWH, 5/16" - 18 x 1"
|
CAS
5/16-18 X 1 HWHTCTS
|
| 15. |
412-48
|
[2] |
CARRIAGE BOLT,Short Sq Nk 1/4" - 20 x 1/2", Gr 2
|
CAS
1/4-20 X 1/2 RHSNB Superseded by part number: 280700
|
| 16. |
231-5144
|
[2] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 17. |
700125911
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - magnet
|
| 18. |
700710211
|
[1] |
ACTUATOR
|
IH
|
| 19. |
700125814
|
[1] |
SUPPORT
|
HFI
Superseded by part number: 700124969
|
| 20. |
172463
|
[7] |
SELF-TAP SCREW,Hex Hd, 5/16" x 1"
|
CAS
5/16-18 X 3/4 HWHTCTS
|
| 21. |
493-81008
|
[7] |
LOCK WASHER,Int Tooth, 5/16"
|
CAS
WASHER - internal tooth lock, 5/16 inch Superseded by part number: 280542
|
| 22. |
700125819
|
[1] |
SUPPORT
|
HFI
WA - right
|
| 23. |
700126767
|
[1] |
REINFORCEMENT
|
HFI
|
| 24. |
700125809
|
[1] |
KNIFE
|
HFI
WA Superseded by part number: 700124960
|
| 25. |
700125813
|
[1] |
SUPPORT
|
HFI
|
| 26. |
700125825
|
[1] |
SUPPORT
|
HFI
WA - right
|
| 27. |
700125713
|
[1] |
PANEL
|
HFI
WA - right Superseded by part number: 700124963
|
| 28. |
700125694
|
[1] |
ROLLER
|
HFI
ASSEMBLY (S.N. CFH0073001 THRU CFH0073197)
|
| . . |
700127934
|
[1] |
ROLLER
|
HFI
ASM. (Overrunning clutch) (S.N. CFH0073198 and later)
|
| 29. |
700125700
|
[1] |
ROLLER
|
HFI
|
| 30. |
51680
|
[2] |
BEARING, BALL
|
CAS
BEARING Superseded by part number: 47577183, 45396
|
| 31. |
700125820
|
[1] |
SHAFT
|
HFI
|
