凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (9-72) - MESH WRAP ROLLER ASSEMBLY, SERIAL NUMBER CFH0073011 THROUGH CFH0073271 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
231 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700125703
|
[1] |
PANEL
|
HFI
WA - left Superseded by part number: 700124962
|
| 2. |
700125821
|
[1] |
SUPPORT
|
HFI
WA - left
|
| 3. |
413-616
|
[12] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 4. |
492-11038
|
[12] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 5. |
425-106
|
[12] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 6. |
700125812
|
[1] |
BUMPER
|
HFI
|
| 7. |
433-512
|
[11] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 8. |
496-21034
|
[23] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 9. |
492-11031
|
[22] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 10. |
425-105
|
[11] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 11. |
413-512
|
[11] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 12. |
700125814
|
[1] |
SUPPORT
|
HFI
Superseded by part number: 700124969
|
| 13. |
700125817
|
[1] |
SUPPORT
|
HFI
WA
|
| 14. |
700126767
|
[1] |
REINFORCEMENT
|
HFI
|
| 15. |
700125809
|
[1] |
KNIFE
|
HFI
WA Superseded by part number: 700124960
|
| 16. |
700125813
|
[1] |
SUPPORT
|
HFI
|
| 17. |
700125825
|
[1] |
SUPPORT
|
HFI
WA - right
|
| 18. |
700125713
|
[1] |
PANEL
|
HFI
WA - RIGHT Superseded by part number: 700124963
|
| 19. |
700125694
|
[1] |
ROLLER
|
HFI
ASSEMBLY (S.N. CFH0073001 thru CFH0073197)
|
| . . |
700127934
|
[1] |
ROLLER
|
HFI
ASM. (Overrunning clutch) (S.N. CFH0073198 and later)
|
| 20. |
700125700
|
[1] |
ROLLER
|
HFI
- rubber
|
| . . |
700130730
|
[1] |
ROLLER
|
HFI
- steel
|
| 21. |
51680
|
[2] |
BEARING, BALL
|
CAS
BEARING Superseded by part number: 47577183, 45396
|
| 22. |
700125820
|
[1] |
SHAFT
|
HFI
|
