神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (04-006) - ALTERNATOR GENERAL P/N ME049171 Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
538 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME049171 | [1] | ALTERNATOR | KOBMEC 24V-80A |
| 3. | VAME047525 | [1] | BRACKET | KOBALTERNATOR Superseded by part number: VAME047420 |
| 4. | VAMH000726 | [2] | BOLT | KOBBOLT, FLANGE, 10 X 22 |
| 5. | VAMH000703 | [1] | BOLT | KOBBOLT, 12 X 125 |
| 6. | VAMF434106 | [1] | NUT | KOBNUT, FLANGE 12 Superseded by part number: 135085A1 |
| 7. | VAME037602 | [1] | PLATE, ADJUSTING | |
| 7A. | VAME021681 | [2] | SPACER | KOBL=20 |
| 8. | VAMF140234 | [2] | SPECIAL BOLT | KOBBOLT, FLANGE, 8 X 45 |
| 9. | VAMH000372 | [1] | SCREW | KOBBOLT, W/WSR, 12 X 30 Superseded by part number: 135147A1 |
