凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (9-96) - SVC KIT, SLOW DOWN MESH WRAP, 700130728 SVC KIT, SLOW DOWN MESH WRAP COMPLETE, Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
461 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700130728
|
[1] |
KIT
|
CAS
SVC - kit mesh wrap slow down complete
|
| 1. |
700130721
|
[1] |
SHIELD
|
CAS
|
| 2. |
121-226
|
[5] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 3. |
231-5146
|
[7] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 4. |
413-612
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 5. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 6. |
700710049
|
[2] |
WASHER
|
CAS
3/8 FENDER WASHER
|
| 7. |
700714214
|
[1] |
SHEAVE
|
CAS
|
| 8. |
413-864
|
[1] |
BOLT,Hex, 1/2" - 13 x 4", Gr 5
|
CAS
1/2-13 X 4 C Superseded by part number: 86505993
|
| 9. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 10. |
6598684
|
[1] |
BUSHING
|
CAS
SPACER
|
| 11. |
50575
|
[2] |
FLANGE
|
NNA
Superseded by part number: 663562R1
|
| 12. |
50468
|
[1] |
SPHERICAL BEARING,38.1 mm ID x 80 mm OD x 22, 43.66 mm
|
IH
- spherical
|
| 13. |
700130720
|
[1] |
ADAPTER
|
CAS
SPACER
|
| 14. |
409-7512
|
[4] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 15. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 16. |
700130846
|
[1] |
HINGE
|
HFI
|
| 17. |
700130723
|
[1] |
ROLLER
|
CAS
- wa
|
| 18. |
409-7812
|
[3] |
BOLT,Hex Flg, 1/2" - 13 x 3/4", Spcl
|
CAS
1/2-13 X 3/4 HFSS Superseded by part number: 86512178
|
| 19. |
T13450
|
[1] |
KEY
|
CAS
1/4 X 1-1/4 KEY
|
| 20. |
700714215
|
[1] |
V-BELT,1066.80 mm L
|
CAS
|
| 21. |
700130722
|
[1] |
SHIM
|
CAS
|
