凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (9-94) - MESH WRAP OVERRUNNING CLUTCH KIT, 700129419 MESH WRAP OVERRUNNING CLUTCH KIT COMPLETE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
117 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700129419
|
[1] |
CLUTCH
|
CAS
OVERRUNNING CLUTCH KIT COMPLETE
|
| 1. |
100-11175
|
[1] |
SNAP RING,#175, Ext
|
CAS
Ring, Snap, #175, Ext Superseded by part number: 11487
|
| 2. |
700127931
|
[1] |
SHEAVE
|
CAS
ASSEMBLY (Includes items 3 and 4)
|
| 3. |
438-11620
|
[1] |
LOCK PIN,1/4" x 1 1/4", Slotted
|
CAS
Pin, 1/4" x 1 1/4", Slotted
|
| 4. |
700713302
|
[1] |
BRONZE BUSHING,44.552 mm ID x 50.902 mm OD x 25.527 mm
|
CAS
BEARING - bronze
|
| 5. |
700127930
|
[1] |
HUB
|
CAS
- ratchet
|
| 6. |
700127932
|
[1] |
PAWL
|
CAS
|
| 7. |
413-612
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 8. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 9. |
700710049
|
[2] |
WASHER
|
CAS
3/8 FENDER WASHER
|
| 10. |
Q10
|
[1] |
KEY,1/4" Sq x 1 3/8"
|
IH
1/4 X 1-3/8 KEY
|
| 11. |
700127933
|
[1] |
SPACER
|
CAS
|
