凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (2-08) - DRIVE SHAFT ASSEMBLY, CLUTCH Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
392 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700109753
|
[1] |
BEARING ASSY,97 mm ID x 108 mm OD x 33 mm
|
CAS
BEARING ASSEMBLY (Includes item 2)
|
| 2. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING Superseded by part number: 47577203
|
| 3. |
700126762
|
[1] |
PLATE
|
HFI
|
| 4. |
700710984
|
[4] |
SCREW,Hex Flg, 1/2" x 1 1/4", G8 NC
|
CAS
1/2-13 X 1-1/4 HFS GR8
|
| 5. |
231-5148
|
[4] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 6. |
433-534
|
[4] |
1/2-13 X 1-1/2 RHSNB
|
|
| 7. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 8. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 9. |
700712511
|
[2] |
DOWEL
|
CAS
5/8 X 3-1/2 PIN - special
|
| 10. |
700127881
|
[1] |
SHAFT
|
HFI
ASSEMBLY (Includes item 9)
|
| 11. |
485-13116
|
[1] |
SET SCREW,Sq Hd, 5/16"-18 x 1", Cup pt
|
CAS
Superseded by part number: 88971
|
| 12. |
425-105
|
[1] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 13. |
700126943
|
[1] |
DISC
|
HFI
WA
|
