| 1. |
700708338
|
[1] |
LINK
|
CAS
#40 CONNECTOR LINK
|
| 2. |
700707710
|
[1] |
CHAIN (AG)
|
CAS
#40 CHAIN - roller, o-ring
|
| 3. |
47977
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - idler, 18 tooth Superseded by part number: 103243
|
| 4. |
61-832
|
[2] |
HEX SOC SCREW,1/2"-13 x 2"
|
CAS
1/2-13 X 2 HSHCS SPECIAL Superseded by part number: 86570628
|
| 5. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 6. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, , straight, taper 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 7. |
231-5348
|
[8] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 8. |
700712789
|
[8] |
STUD
|
CAS
1/2-13 STUD
|
| 9. |
700101219
|
[2] |
ADJUSTING PLATE
|
HFI
SHIM
|
| 10. |
700710131
|
[1] |
TRANSFER BOX
|
IH
GEARBOX Superseded by part number: 700725114
|
| 11. |
700129354
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - pump
|
| 12. |
700127889
|
[1] |
MOUNTING PLATE
|
HFI
MOUNT - sensor
|
| 13. |
700125101
|
[1] |
PLATE
|
HFI
SUPPORT
|
| 14. |
111-622
|
[1] |
CARRIAGE BOLT,Short NK 5/8" -11 x 2 1/4", G5
|
CAS
5/8-11 X 2-1/4 RHSNB
|
| 15. |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 16. |
425-1010
|
[1] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 17. |
700127890
|
[1] |
SUPPORT
|
HFI
|
| 18. |
700126366
|
[1] |
SUPPORT
|
HFI
WA (Includes item 19)
|
| 19. |
740514
|
[1] |
BUSHING,31.81mm ID x 38.2mm OD x 50.8mm L
|
L
- oilite
|
| 20. |
219-90
|
[1] |
LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF
|
CAS
1/4-28 X 45° ZERK Superseded by part number: 87569
|
| 21. |
700118822
|
[1] |
SPACER
|
CAS
|
| 22. |
52175
|
[1] |
BUSHING,25.48mm ID x 38.2mm OD x 3.17mm L
|
CAS
5/8 X 18 GAUGE NRMB
|
| 23. |
700708998
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - 40B17 tooth
|
| 24. |
114-102
|
[1] |
BOLT,Hex, 5/16" - 24 x 3/4", Gr 5
|
CAS
Superseded by part number: 280559
|
| 25. |
492-11031
|
[1] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 26. |
495-61034
|
[2] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
