神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (08-001) - CYLINDER BLOCK REPAIR KIT P/N ME999916 Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
231 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-25. | VAME999916 | [1] | CRANKCASE ASSY 6D15, 15T | CRANKCASE ASSY 6D15, 15T |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCRANKCASE, ME071221 |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONCAP, BRG FR & MI, ME031914 |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONCAP, BRG RE, ME031915 |
| 4. | VAME031865 | [14] | SCREW | KOB14 X 108 |
| 5. | VAME071064 | [6] | LINER, ENGINE CYLIND | KOBCYL |
| 6. | VAME031610 | [12] | O-RING | KOB |
| 7. | VAME071066 | [6] | PACKING | KOB |
| 8. | VAMH012041 | [6] | PIN | KOBPIN, SPG, 1 X 10 |
| 9. | VAMH037137 | [2] | PLUG | KOBPLUG 20 |
| . . | VAMF660068 | [2] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 12. | VAMH007011 | [1] | PIN | KOBPIN, DOWEL, 12 X 34 Superseded by part number: 132324A1 |
| 13. | VAMF665535 | [1] | CAP | KOBCAP, SEALING 18 |
| 1A. | VAMH007010 | [1] | PIN | KOBPIN, DOWEL, 12 X 17 |
| 15. | VAMF472404 | [2] | DOWEL | KOBPIN, DOWEL, 8 X 18 Superseded by part number: MF472404 |
| 16. | VAMH037082 | [2] | PLUG PLUG, 6.5 X 8 | PLUG PLUG, 6.5 X 8 |
| 17. | VAME071141 | [1] | BUSHING | KOB1 |
| 18. | VAME071142 | [1] | BUSHING | KOB2 |
| 19. | VAME071143 | [1] | BUSHING | KOB3 |
| 20. | VAME071144 | [1] | BUSHING | KOB4 Superseded by part number: VAME071862 |
| 21. | VAME031087 | [1] | SET OF SCREWS | KOB |
| . . | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 21A. | VAME031087 | [1] | SET OF SCREWS | KOB |
| 24. | VAME031088 | [1] | PLUG | KOB |
| 25. | VAMS666222 | [1] | PLUG | SMPLUG, TAPER, PT3/8 |
