神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (03-002) - FUEL INJECTION PUMP GENERAL P/N ME070761 Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
894 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-5. | VAME070761 | [1] | CORE-INJECTION PUMP | KOBGENERAL ASSY, M2 ONLY |
| . . | VAME070760 | [1] | FUEL INJECTION PUMP | KOBM1 ONLY |
| 1-6. | VAME043033 | [1] | INJECTION PUMP GENERAL ASSY, M8 ONLY | INJECTION PUMP GENERAL ASSY, M8 ONLY |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY, A TYPE, ME723427 |
| 2. | VAME716986 | [1] | GOVERNOR ASSY, RSV TYPE, M2 ONLY | |
| . . | VAME726399 | [1] | RSV TYPE, M1 ONLY | |
| . . | NSS | [1] | NOT SOLD SEPARAT | CONRFD TYPE, M8 ONLY |
| 3. | VAME036005 | [1] | PUMP | KOBFUEL ASSY, KE TYPE Superseded by part number: VAME717109 |
| 5. | VAME723426 | [1] | COUPLING | KOB |
| 6. | VAME066028 | [1] | CAP, SEAL, M8 ONLY | |
| 7. | VAME035679 | [1] | CLUTCH DISC | KOBCLUTCH DISK DRIVING Superseded by part number: VAME076553 |
| 8. | VAMH035500 | [1] | O-RING | KOBO-RING 140 |
| 9. | VAME047182 | [1] | STAY | KOBM1 & M2 ONLY |
| . . | VAME036954 | [1] | M8 ONLY | |
| 10. | VAMF140223 | [2] | BOLT | KOBBOLT, FLANGE, 8 X 16, M1 & M2 ONLY |
| 11. | VAMH005068 | [2] | WASHER | KOBWASHER, PLAIN 10, M1 & M2 ONLY |
| 14. | VAMF434105 | [4] | NUT | KOBNUT, FLANGE 10 |
| 15. | VAMF434105 | [1] | NUT | KOBNUT, FLANGE 10 |
| 16. | VA3186090600 | [1] | LEVER | KOBLEVER, STOP M1 ONLY |
| 17. | VAMF140207 | [1] | SHOCK ABSORBER BOLT, FLANGE, 6 X 20, M1 ONLY | SHOCK ABSORBER BOLT, FLANGE, 6 X 20, M1 ONLY |
| . . | VAMF434103 | [1] | NUT | KOBNUT, FLANGE 6, M1 ONLY |
| 24. | VAME036955 | [1] | SPACER, M8 ONLY | |
