神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (03-013) - FUEL INJECTION PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
840 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME039641 | [1] | PIPE INJECTION NO. 1 | PIPE INJECTION NO. 1 |
| 2. | VAME039642 | [1] | PIPE INJECTION NO. 2 | PIPE INJECTION NO. 2 |
| 3. | VAME039643 | [1] | PIPE INJECTION NO. 3 | PIPE INJECTION NO. 3 |
| 4. | VAME039644 | [1] | PIPE INJECTION NO. 4 | PIPE INJECTION NO. 4 |
| 5. | VAME039645 | [1] | PIPE INJECTION NO. 5 | PIPE INJECTION NO. 5 |
| 6. | VAME039646 | [1] | PIPE INJECTION NO. 6 | PIPE INJECTION NO. 6 |
| 7. | VAMH020258 | [5] | CLAMP | KOBCLAMP Superseded by part number: 134717A1 |
| 8. | VAMH020259 | [1] | CLAMP | KOBCLAMP Superseded by part number: 134718A1 |
| 9. | VAMH020260 | [1] | CLAMP | KOBCLAMP |
| 10. | VAMH021252 | [1] | CLAMP | KOBCLAMP |
| 11. | VAMF240029 | [3] | SCREW | KOBBOLT, W/WSR, 6 X 25 |
| 12. | VAMF434103 | [2] | NUT | KOBNUT, FLANGE 6 |
