凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (4-04) - MISCELLANEOUS ELECTRICAL ASSEMBLIES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
149 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700122574
|
[3] |
SUPPORT
|
CAS
- actuator
|
| 2. |
64667
|
[4] |
FLEXIBLE HOSE
|
CAS
POP RIVET Superseded by part number: 51200829, 51200829, NLS
|
| 3. |
700709996
|
[3] |
SWITCH
|
IH
ACTUATOR
|
| 4. |
700122570
|
[1] |
SUPPORT
|
HFI
- switch
|
| 5. |
700710208
|
[5] |
ROTARY SWITCH
|
L
SWITCH - assembly
|
| 6. |
700710199
|
[10] |
GROMMET
|
CAS
|
| 7. |
700710187
|
[8] |
WASHER
|
CAS
#6 WPW STAINLESS STEEL
|
| 8. |
515-2179
|
[5] |
CLAMP,5/16", Insul, 1/4" Bolt
|
CAS
Superseded by part number: 237910
|
| 9. |
700122476
|
[1] |
SUPPORT
|
HFI
- switch
|
| 10. |
869707C1
|
[1] |
STRAP,368.3mm L
|
IH
TIE - cable Superseded by part number: 529070
|
| 11. |
700707683
|
[1] |
DECAL
|
CAS
- notice, 12 volt
|
| 12. |
700707598
|
[1] |
WIRE HARNESS
|
IH
CABLE ASSEMBLY
|
| 13. |
700710794
|
[1] |
HARNESS
|
CAS
- wire
|
| 14. |
700114077
|
[1] |
SUPPORT
|
CAS
- control box
|
| 15. |
700707295
|
[2] |
KNOB
|
CAS
|
| 16. |
163-14
|
[3] |
SCREW,Hex Wshr Hd, 1/4" - 20 x 1"
|
CAS
1/4-20 X 1 HWHMS
|
| 17. |
231-5144
|
[3] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 18. |
700707294
|
[2] |
PUSH-ON NUT
|
CAS
RUBBER WELL NUT Superseded by part number: 694147
|
| 19. |
700714213
|
[1] |
CONTROL
|
CAS
BOX COMPLETE (S.N. 565A-00101 thru 565A-01373) Superseded by part number: 700715547
|
| . . |
700715547
|
[1] |
CONTROL
|
HFI
BOX COMPLETE (S.N. 565A-01374 and later)
|
| 20. |
223-34
|
[1] |
FUSE,7 1/2 Amp, Type 3AG
|
CAS
- 7.5 amp Superseded by part number: FFC14599B
|
| 21. |
700150828
|
[1] |
KIT
|
HFI
EPROM 7.6 CHIP SERVICE KIT
|
| 22. |
700122568
|
[1] |
SUPPORT
|
HFI
- switch
|
| 23. |
700710188
|
[22] |
SCREW
|
CAS
#6-32 X 3/4 CRPHMS GR2
|
| 24. |
700710189
|
[22] |
LOCK NUT
|
CAS
#6-32 LHSN
|
| 25. |
700122573
|
[1] |
SUPPORT
|
HFI
- switch
|
| 26. |
700128332
|
[1] |
SUPPORT
|
HFI
- switch
|
