凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (4-06) - SWITCH ASSEMBLY, 700129394 SWITCH ASSEMBLY COMPLETE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
520 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700129394
|
[1] |
SWITCH
|
CAS
ASSEMBLY COMPLETE
|
| 1. |
700130713
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING - switch
|
| 2. |
858183
|
[1] |
SPRING
|
CAS
- compression
|
| 3. |
700127956
|
[1] |
PLATE
|
HFI
- wear, assembly
|
| 4. |
700127896
|
[1] |
SUPPORT
|
HFI
|
| 5. |
700122575
|
[1] |
BUTTON
|
CAS
- nylon
|
| 6. |
700129393
|
[1] |
BUTTON
|
CAS
PLUNGER - nylon
|
| 7. |
700127953
|
[1] |
DISC
|
HFI
- switching
|
| 8. |
700127003
|
[1] |
PLATE
|
HFI
- delay
|
| 9. |
413-58
|
[1] |
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5
|
CAS
5/16-18 X 1/2 C Superseded by part number: 72187203, 88574
|
| 10. |
231-5145
|
[1] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT - hex serrated flange, 5/16 inch NC Superseded by part number: 72187067, 145458
|
| 11. |
700712515
|
[1] |
WASHER
|
CAS
- washer
|
| 12. |
8025637
|
[1] |
SWITCH
|
L
|
| 13. |
700713335
|
[1] |
WASHER
|
CAS
SHIM - washer
|
| 15. |
496-11028
|
[1] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 86632587
|
| 16. |
492-11025
|
[1] |
LOCK WASHER,1/4"
|
CAS
WASHER, LOCK, 1/4" Superseded by part number: 72187247, 80682
|
| 17. |
425-104
|
[1] |
NUT,1/4"-20, Cl 5
|
CAS
Superseded by part number: 7770, 72187220
|
| 14. |
413-420
|
[1] |
BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 87716, 72187191
|
