| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 197-3798 | [1] | EXTENSION AS(LH) | |
| 2. | 197-3799 | [1] | EXTENSION AS(RH) | |
| 3. | 242-7471 | [1] | COVER(FENDER, LH) | |
| 4. | 246-5368 | [1] | COVER(FENDER, RH) | |
| 5. | 5C-7261M | [18] | NUT(M8X1.25-THD) | |
| 6. | 5P-4116 | [18] | WASHER-HARD(8.8X20.5X2-MM THK) | |
| 7. | 8T-4908M | [18] | BOLT(M8X1.25X25-MM) | |
| 8. | 7X-0579 | [18] | WASHER-HARD(8.8X25.5X2-MM THK) | |
| M | METRIC PART | |||
