| 1. |
496-11041
|
[4] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 2. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 3. |
700116206
|
[1] |
SPECIAL BOLT
|
IH
DRAWBOLT
|
| 4. |
396-21066
|
[3] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 5. |
425-1010
|
[3] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 6. |
700711989
|
[1] |
BOLT,Hex, 5/8" - 11 x 4 1/2", Gr 8
|
CAS
5/8-11 X 4-1/2 C, special
|
| 7. |
700118716
|
[3] |
WASHER
|
CAS
- special
|
| 8. |
H757815
|
[1] |
PORT
|
CAS
ORIFICE - .038
|
| 9. |
218-5105
|
[5] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
- 90° (Includes item 36) Superseded by part number: 76344, 72186128
|
| 10. |
700710983
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 2475.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 2475.00 mm, SAE 100R1
|
| 11. |
700709416
|
[1] |
CYLINDER
|
CAS
- hydraulic, threader (S.N. CFH0077001 thru CFH0077005) Superseded by part number: 700712122
|
| . . |
700712122
|
[1] |
CYLINDER
|
CAS
- hydraulic, threader (S.N. CFH0077006 and later)
|
| 12. |
413-1044
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5
|
CAS
SCREW, Hex, 5/8"-11 x 2 3/4", G5 Superseded by part number: 88693
|
| 13. |
L18337
|
[1] |
CABLE TIE,9.95"-12.1" lg
|
CAS
STRAP - tie, 15 inch, nylon Superseded by part number: 529070
|
| 14. |
700707389
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 2275.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 2275.00 mm, SAE 100R1
|
| 15. |
7021728
|
[3] |
STRAP
|
CAS
TIE - cable Superseded by part number: 529070, 529070, NLS
|
| 16. |
700117735
|
[2] |
ADHESIVE STRIP
|
CAS
TRIM
|
| 17. |
700116123
|
[2] |
CLAMP
|
HFI
|
| 18. |
413-532
|
[1] |
BOLT,Hex, 5/16" - 18 x 2", Gr 5
|
CAS
Superseded by part number: 9636711
|
| 19. |
231-5145
|
[1] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 20. |
6501076
|
[1] |
SPACER
|
HFI
|
| 21. |
515-23254
|
[1] |
CLAMP,1", Insul, 3/8" Bolt
|
CAS
Line 1", Insul, 3/8" Bolt Superseded by part number: 9827902, 72187281
|
| 22. |
237-6008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk Superseded by part number: 128825
|
| 23. |
237-6004
|
[1] |
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
|
CAS
4-1, 90 Duro, .351" ID x .072" Thk Superseded by part number: 165202, 72186131
|
| 24. |
700709241
|
[1] |
HYDRAULIC HOSE,12.70 mm ID x 1400.00 mm, SAE 100R1
|
CAS
12.70 mm ID x 1400.00 mm, SAE 100R1
|
| 25. |
218-5053
|
[1] |
HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB
|
CAS
CONNECTOR (Incl. item 22) Superseded by part number: 265235
|
| 26. |
218-5136
|
[1] |
ELBOW,45 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
|
CAS
(Incl. item 23) 45º, 3/4"-16, 37º x 3/4"-16, O-Ring Superseded by part number: 72186187, 216797
|
| 27. |
413-648
|
[1] |
BOLT,Hex, 3/8" - 16 x 3", Gr 5
|
CAS
Superseded by part number: 280161
|
| 28. |
231-5146
|
[1] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 29. |
700708999
|
[1] |
TUBE,25.4 mm OD, 783, 400 mm Length
|
CAS
LINE - hydraulic
|
| 30. |
218-5047
|
[1] |
HYD CONNECTOR,1-5/16" - 12 Male JIC x 1-3/16" - 12 Male ORB
|
CAS
CONNECTOR - flared (Includes item 31) Superseded by part number: 9615397
|
| 31. |
237-6014
|
[1] |
O-RING,0.116" Thk x 1.048" ID, -914, Cl 6, 90 Duro
|
CAS
14-1, 90 Duro, 1.048" ID x .116" Thk Superseded by part number: 70921886
|
| 32. |
700708580
|
[1] |
PUMP
|
CAS
- piston
|
| 33. |
738484
|
[1] |
O-RING
|
IH
Superseded by part number: 167266
|
| 34. |
413-624
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187209, 88044
|
| 35. |
492-11038
|
[2] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 36. |
738468
|
[5] |
O-RING
|
IH
|
| 37. |
700708944
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 1875.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 1875.00 mm, SAE 100R1 Superseded by part number: 97478C1, 84384
|
| 38. |
700707387
|
[1] |
HYDRAULIC HOSE,6.35 mm ID x 1825.00 mm, SAE 100R1
|
CAS
6.35 mm ID x 1825.00 mm, SAE 100R1
|
| 39. |
320993R1
|
[2] |
SPACER,7/8" Tube x 1/2"
|
IH
|
| 40. |
7075625
|
[1] |
CYLINDER
|
L
- hydraulic, clutch (S.N. CFH0077001 thru CFH0077005) Superseded by part number: 700726495
|
| . . |
700711910
|
[1] |
CYLINDER ASSY.
|
IH
CYLINDER - hydraulic, clutch (S.N. CFH0077006 and later)
|
| 41. |
254409
|
[2] |
SPACER
|
HFI
|
| 42. |
432-1020
|
[2] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
PIN, SPLIT (COTTER), 5/32" x 1 1/4" Superseded by part number: 86523851
|
| 43. |
863498
|
[2] |
CLEVIS PIN
|
CAS
5/8 X 3-1/2 CLEVIS PIN
|
| 44. |
218-483
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 1/4" - 18 Male NPTF
|
CAS
- 90° Superseded by part number: 578384
|
| 45. |
700119118
|
[1] |
SPACER
|
HFI
|
