凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (8-04) - HYDRAULIC PISTON PUMP ASSEMBLY, 700708580 HYDRAULIC PISTON PUMP ASSEMBLY COMPLETE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
865 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700708580
|
[1] |
PUMP
|
CAS
PISTON PUMP ASSEMBLY COMPLETE
|
| 1. |
700709151
|
[1] |
PUMP
|
CAS
COMPENSATOR ASSEMBLY
|
| 2. |
413-520
|
[4] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
5/16-18 X 1-1/4 C Superseded by part number: 87657
|
| 3. |
700709134
|
[1] |
BACK PLATE
|
CAS
BACKPLATE
|
| 4. |
700709133
|
[1] |
BEARING
|
CAS
- backplate
|
| 5. |
700709123
|
[1] |
KIT
|
CAS
- rotating Superseded by part number: 276521
|
| 6. |
700709125
|
[1] |
PISTON
|
CAS
- control
|
| 7. |
D23692
|
[2] |
SNAP RING,#100, Ext, Crescent
|
CAS
Ring, Snap, #100, Ext, Crescent
|
| 8. |
700700942
|
[1] |
BEARING
|
CAS
- thrust
|
| 9. |
100-21162
|
[1] |
SNAP RING,1.625", Int, #162
|
CAS
Ring, Snap, 1.625", Int, #162 Superseded by part number: 81821513
|
| 10. |
D63314
|
[1] |
WASHER
|
CAS
Superseded by part number: 272459
|
| 11. |
700700941
|
[2] |
RACE
|
CAS
- bearing-thrust
|
| 12. |
700709131
|
[1] |
KEY
|
CAS
|
| 13. |
700709119
|
[1] |
SHAFT
|
CAS
- drive
|
| 14. |
F62086
|
[1] |
NEEDLE BEARING,Needle, 25.4mm ID x 33.34mm OD x 25.4mm W
|
CAS
BEARING - housing
|
| 15. |
700709122
|
[1] |
HOUSING
|
CAS
|
| 16. |
700709130
|
[1] |
SPRING
|
CAS
|
| 17. |
700709126
|
[1] |
COLLAR
|
CAS
- spring
|
| 18. |
700709127
|
[1] |
BUTTON
|
CAS
- pivot
|
| 19. |
700706559
|
[1] |
ROLL PIN
|
HFI
|
| 20. |
700709128
|
[1] |
LARGE PLATE
|
CAS
CAM PLATE
|
| 21. |
D61963
|
[2] |
BEARING, CONE
|
CAS
RACE - inner Superseded by part number: 272454
|
| 22. |
700709129
|
[2] |
BEARING
|
CAS
- trunnion
|
| 23. |
D61975
|
[2] |
COVER
|
CAS
- trunnion
|
| 24. |
100-21150
|
[2] |
SNAP RING,1.50", Int, #150
|
CAS
Ring, Snap, , Trunnion 1.50", Int, #150 Superseded by part number: 167111
|
| 25. |
700709132
|
[1] |
KIT
|
CAS
SEAL AND O-RING KIT Includes: Ref. marked with asterisks in art
|
