| 1. |
237-6008
|
[4] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
8-1, 90 Duro, .644" ID x .087" Thk Superseded by part number: 128825
|
| 2. |
121-226
|
[3] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 3. |
231-5146
|
[3] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 4. |
700711782
|
[1] |
GAUGE
|
CAS
Superseded by part number: 700722353
|
| 5. |
440-1068
|
[3] |
SCREW,Cross Pan Hd, #6-32 x 1/2"
|
CAS
#6-32 X 1/2 CRPHMS Superseded by part number: 281007
|
| 6. |
492-11006
|
[3] |
LOCK WASHER,#6
|
CAS
Washer, Lock, #6 Superseded by part number: 87276
|
| 7. |
225-14106
|
[3] |
NUT,#6-32
|
CAS
Superseded by part number: 88458, 87779111
|
| 8. |
218-513
|
[1] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 1/4"-18, Fem NPTF
|
CAS
- 90° Superseded by part number: 9402903
|
| 9. |
812382C1
|
[1] |
HYDRAULIC HOSE
|
IH
HOSE - hydraulic
|
| 10. |
515-23190
|
[1] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86624005
|
| 11. |
700708068
|
[3] |
CLEVIS PIN,15.77mm OD x 68.66mm L
|
IH
5/8 X 2-1/2 CLEVIS PIN
|
| 12. |
746529
|
[1] |
ELBOW
|
CAS
- 90°
|
| 13. |
700707872
|
[1] |
ORIFICE
|
CAS
|
| 14. |
700707399
|
[1] |
HOSE
|
CAS
- hydraulic (Includes item 16)
|
| 15. |
700707601
|
[1] |
HOSE
|
CAS
- hydraulic (Includes item 1)
|
| 16. |
738468
|
[10] |
O-RING
|
IH
|
| 17. |
700709959
|
[1] |
BREATHER
|
CAS
(Includes item 16) (S.N. CFH0077001 thru CFH0077646)
|
| 18. |
218-1575
|
[4] |
TEE,37 Degree, 9/16"-18 x 3/4"-16, Br
|
CAS
Superseded by part number: 86624134
|
| 19. |
8742447
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 20. |
700707276
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 21. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
- 90° (Includes item 16) Superseded by part number: 76344, 72186128
|
| 22. |
700707262
|
[3] |
CYLINDER
|
CAS
- hydraulic (S.N. CFH0077001 thru CFH0077005) Superseded by part number: 700712161
|
| . . |
700712161
|
[3] |
CYLINDER ASSY.,Double Acting, 38.1mm Rod, 304.8mm Stroke
|
IH
CYLINDER - hydraulic (S.N. CFH0077006 and later)
|
| 23. |
700707386
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 24. |
218-5230
|
[2] |
ELBOW,90 Degree, 3/4"-16, 37 Degree x 3/4"-16, 37 Degree Fem Sw
|
CAS
Superseded by part number: 72187024, 248974
|
| 25. |
700707285
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 26. |
700710626
|
[1] |
CYLINDER
|
CAS
- hydraulic (S.N. CFH0077001 thru CFH0077005)
|
| . . |
700712159
|
[1] |
CYLINDER ASSY.
|
IH
CYLINDER - hydraulic (S.N. CFH0077006 and later)
|
| 27. |
396-21066
|
[3] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 28. |
218-5243
|
[1] |
TEE,9/16" - 18 Male JIC x 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
(Includes item 16) 9/16"-18, 37º x 9/16"-18, O-Ring Run Superseded by part number: 86513020
|
| 29. |
L18337
|
[3] |
CABLE TIE,9.95"-12.1" lg
|
CAS
STRAP - tie, 15 inch, nylon Superseded by part number: 529070
|
| 30. |
700113862
|
[1] |
HOSE,50.00'
|
CAS
Tube, , Vent 50 Foot Bulk Length 50.00'
|
| 31. |
700713394
|
[1] |
TEE
|
CAS
- male run
|
| 32. |
8042715
|
[1] |
HYDRAULIC HOSE,9.65 mm ID x 787.00 mm, SAE 100R1,SAE J517,SAE J343,SAE J516
|
CAS
9.65 mm ID x 787.00 mm, SAE 100R1,SAE J517,SAE J343,SAE J516
|
| 33. |
218-5057
|
[1] |
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
|
CAS
CONNECTOR (Incl. item 16) Superseded by part number: 76350
|
| 34. |
218-5090
|
[2] |
ADAPTER
|
CAS
(Includes item 16)
|
| 35. |
432-1020
|
[3] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
PIN, SPLIT (COTTER), 5/32" x 1 1/4" Superseded by part number: 86523851
|
| 36. |
700118823
|
[2] |
PIN
|
IH
WA
|
| 37. |
700707395
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 38. |
700707394
|
[2] |
HOSE
|
CAS
- hydraulic (Includes item 1)
|
| 39. |
218-5182
|
[1] |
TEE,9/16" - 18 Male JIC x 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
(Includes item 16) Superseded by part number: 163335
|
| 40. |
218-5059
|
[1] |
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
|
CAS
CONNECTOR (Incl. item 1) Superseded by part number: 128818
|
