卡特零件查询（725） 341-8583: PUMP GP-LUBRICATION
广数供应链运营团队, 14 02月, 2025，浏览：
603 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 196-1047 | [1] | COVER GP(LUBRICATION TANK) | |
| 2. | 196-1049 | [1] | GUIDE-ROD | |
| 3. | 196-1053 | [1] | COVER GP(LUBRICATION PUMP) | |
| 4. | 196-1056 | [1] | SEAL-O-RING | |
| 5. | 196-1062 | [1] | FILTER AS-GREASE | |
| 6. | 196-1066 | [1] | HARNESS AS-CONTROL(AUTOMATIC LUBRICATION) | |
| 7. | 196-1070 | [2] | CONNECTOR | |
| 8. | 196-1074 | [1] | BOARD AS-CIRCUIT | |
| 9. | 355-2253 | [1] | PUMP-LUBRICATION | |
| 10. | 355-2254 | [1] | VALVE AS | |
| 11. | 355-2255 | [1] | SENSOR AS-LIQUID LEVEL(GREASE) | |
| 12. | 355-2260 | [1] | SWITCH AS-PUSH BUTTON(AUTOMATIC LUBRICATION PUMP) | |
| 13. | 355-2265 | [1] | TANK AS-LUBRICATION | |
| 14. | 196-1054 | [1] | SEAL | |
