神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE FOR K904C, K907B, K907C & YS750-2 (1/77-12/06) (01-024) - AIR COMPRESSOR GENERAL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
1010 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME038665 | [1] | COMPRESSOR AIR COMPRESSOR ASSY 186.2CC (FOR M1 TO M4 & M6 TO M8) | COMPRESSOR AIR COMPRESSOR ASSY 186.2CC (FOR M1 TO M4 & M6 TO M8) |
| . . | VAME038666 | [1] | AIR COMPRESSOR ASSY 186.2CC (FOR M5 ONLY) | |
| 2. | VAME038015 | [1] | GEAR GEAR, A/COMPR Z=42 | GEAR GEAR, A/COMPR Z=42 |
| 3. | VAMF520423 | [1] | O-RING | KOBO-RING 135 Superseded by part number: VAF315313500 |
| 4. | VAMF300851 | [2] | BOLT BOLT, W/WSR 10X50 | BOLT BOLT, W/WSR 10X50 |
| 5. | VAMF300003 | [1] | BOLT | KOBB0LT, W/WSR 10X25 |
| 7. | VAME038215 | [1] | PIPE, AIR SUCTION | |
| 8. | VAMH032209 | [1] | HOSE | KOBHOSE, RUBBER |
| 9. | VAMS666011 | [2] | HOSE CLAMP | KOBCLAMP, HOSE 25 |
| 10. | VAME038001 | [1] | ELBOW, AIR SUCTION (FOR M1 TO M4, M7, M8) | |
| 11. | VAMF244853 | [1] | BOLT | KOBBOLT, W/WSR 8X25 |
| 12. | VAME020915 | [2] | WASHER,PLAIN | |
| 13. | VAMF650102 | [1] | SCREW | KOBBOLT,EYE 10X20 ( FOR M4 TO M8 ) |
| . . | VAMF660063 | [2] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 14. | VAME068004 | [1] | JOINT,EYE (FOR M8 ONLY) | |
| . . | VA3187590400 | [1] | PIPE PIPE,AIR OUTLET (FOR M3 TO M7) | PIPE PIPE,AIR OUTLET (FOR M3 TO M7) |
| 15. | VA1614304702 | [1] | BOLT BOLT,UNION (FOR M3 TO M8) | BOLT BOLT,UNION (FOR M3 TO M8) |
| . . | VAMF660068 | [2] | PACKING | KOBGASKET 20 ( FOR M1 & M3 TO M8) Superseded by part number: VAF420220000 |
| 16. | VA3187591500 | [1] | BRACKET,AIR PIPE (FOR M3 TO M7) | |
| 16A. | VAMH005027 | [2] | WASHER | KOBWASHER,PLAIN (FOR M7 ONLY) |
| 17. | VAMF430731 | [1] | NUT | KOBNUT 20 (FOR M3 TO M7) Superseded by part number: 132633A1 |
| 18. | VAMF650003 | [1] | JOINT, EYE (FOR M8 ONLY) | |
| . . | VA3187590700 | [1] | PIPE, UNLOADER (FOR M4 TO M7) | |
| 19. | VAMF430728 | [1] | NUT | KOBNUT 14 (FOR M4 TO M7 Superseded by part number: 132634A1 |
| 41-45. | VAMC802148 | [1] | GOVERNOR | KOBPRESSURE GOVERNOR ASSY 6.4-7.3 |
| . . | VAMC802150 | [1] | GOVERNOR | KOBPRESSURE GOVERNOR ASSY 7.1-8.0 |
| 41. | NSS | [1] | NOT SOLD SEPARAT | CONBODY, GOV |
| 42-45. | VAMC802151 | [1] | KIT, ENGINE TOP GASK | KOBPRESSURE GOVERNOR KIT (MC802151) Superseded by part number: 77268813, VA4087070100 |
| 42. | VAME705602 | [1] | DIAPHRAGM | KOBDIAPHRAGM ASSY (FOR M3 & M8) |
| 43. | VAMC821656 | [1] | O-RING (FOR M3 & M8) | |
| 44. | VAME705601 | [1] | SLEEVE (FOR M3 & M8) | |
| 45. | VAME705603 | [1] | CAP ASSY (FOR M3 & M8) | |
| 46. | VAMH035107 | [3] | GASKET | KOBGASKET (FOR M3) Superseded by part number: VAMH035195 |
