沃尔沃零件查询AD31D; AD31D-A; AD31XD; TAMD31D; TMD31DTransmissionsHydraulic Pump and Trim InstrumentEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
935 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
873051
|
[1] |
Hydraulic pump
|
Repl by 3857265
|
| 1. |
3857265
|
[1] |
Hydraulic pump
|
|
| 1. |
3861027
|
[1] |
Kit
|
|
| 2. |
854525
|
[1] |
Electric motor
|
|
| 3. |
3858072
|
[1] |
Connector
|
|
| 4. |
3858073
|
[1] |
O-ring
|
|
| 5. |
854528
|
[1] |
Valve housing
|
For 873051
|
| 5. |
3857003
|
[1] |
Adapter
|
For 3857265
|
| 6. |
3858076
|
[2] |
Filter
|
|
| 7. |
854531
|
[1] |
Reservoir
|
|
| 8. |
3858078
|
[1] |
Seal
|
|
| 9. |
3858079
|
[1] |
Cap
|
|
| 10. |
854534
|
[1] |
Small parts kit
|
|
| 11. |
854535
|
[1] |
Hydraulic pump
|
|
| 12. |
873057
|
[1] |
Delivery valve
|
|
| 13. |
854537
|
[1] |
Pressure box
|
|
| 14. |
854438
|
[1] |
Bracket
|
|
| 15. |
970945
|
[2] |
Hexagon screw
|
|
| 16. |
941908
|
[2] |
Spring washer
|
|
| 17. |
854357
|
[2] |
Relay
|
|
| 18. |
948663
|
[2] |
Flange screw
|
|
| 19. |
941905
|
[2] |
Spring washer
|
|
| 20. |
955780
|
[2] |
Hexagon nut
|
|
| 21. |
|
|
|
See group 30
|
| 22. |
948211
|
[1] |
Cable tie
|
|
| 23. |
853097
|
[1] |
Sign
|
|
| 24. |
968476
|
[4] |
Flange screw
|
|
| 25. |
952630
|
[4] |
Clamp
|
|
| 26. |
872498
|
[1] |
Trimmer
|
|
| 27. |
858643
|
[1] |
Front ring
|
|
| 28. |
856821
|
[1] |
Cable kit
|
|
| 29. |
853066
|
[1] |
Cable block
|
For double steering positions.
|
| 30. |
|
|
|
See group 30
|
| 31. |
1324492
|
[2] |
Relay
|
Nb! changed polarity. see mounting instruction., With built in diod
|
| 32. |
949666
|
[1] |
Cable tie
|
|
| 33. |
3855650
|
[1] |
Control panel
|
(873617), (853846)
|
| 34. |
853032
|
[1] |
Cable block
|
|
| 34. |
948294
|
[1] |
Housing
|
9-pole
|
| 34. |
965822
|
[1] |
Cable terminal
|
3,5x1x2,5
|
| 34. |
853498
|
[1] |
Anode kit
|
3-pole
|
| 34. |
853521
|
[1] |
Cable terminal
|
For 853498
|
| 35. |
873228
|
[1] |
Hydraulic hose
|
|
| 36. |
873229
|
[1] |
Hydraulic hose
|
|
