现代零件查询R140W-7 MAIN CONTROL VALVE(2/4, #0199-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
184 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
MAIN CONTROL VALVE
|
|
| 18. |
XKBF-00018
|
[6] |
PLUG
|
|
| 19. |
XKBF-00019
|
[5] |
POPPET 1
|
|
| 20. |
XKBF-00020
|
[5] |
SPRING
|
|
| 21. |
XKBF-00021
|
[5] |
PLUG
|
|
| 22. |
XKBF-00022
|
[5] |
POPPET 2
|
|
| 23. |
XKBF-00023
|
[5] |
SPRING
|
|
| 24. |
XKBF-00094
|
[1] |
RELIEF VALVE-MAIN
|
|
| 25. |
XKBF-00486
|
[4] |
RELIEF VALVE-OVERLOAD
|
|
| 27. |
XKBF-00487
|
[1] |
PLUG-RELIEF VALVE
|
|
| 59. |
XKBF-00488
|
[1] |
PLUG-PARALLEL
|
|
| 61. |
XKBF-00489
|
[1] |
PLUG-ORIFICE
|
|
| 68. |
XKBF-00068
|
[1] |
PLUG-SOCKET HEAD
|
|
| 70. |
XKBF-00061
|
[1] |
PLUG-ORIFICE
|
|
| 72. |
XKBF-00058
|
[5] |
PLUG
|
|
| 76. |
XKBF-00076
|
[2] |
O-RING
|
|
| 78. |
XKBF-00078
|
[2] |
O-RING
|
|
| 80. |
XKBF-00080
|
[5] |
O-RING
|
|
| 81. |
XKBF-00081
|
[7] |
O-RING
|
|
| 83. |
XKBF-00083
|
[1] |
O-RING
|
|
| 84. |
XKBF-00084
|
[6] |
O-RING
|
|
| 86. |
XKBF-00086
|
[2] |
BACK-UP RING
|
|
| 88. |
XKBF-00088
|
[2] |
RING-BACK UP
|
|
