现代零件查询R140W-7 QUICK CLAMP ASSYEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
624 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31N4-95710
|
[1] |
QUICK CLAMP ASSY
|
|
| . |
31N4-95711
|
[1] |
QUICK CLAMP ASSY
|
|
| 1. |
XKBP-00001
|
[1] |
BODY
|
|
| 2. |
XKBP-00002
|
[1] |
CYLINDER ASSY
|
|
| 2-1. |
XKBP-00028
|
[1] |
VALVE-CHECK
|
|
| 2-2. |
XKBP-00029
|
[1] |
CYLINDER
|
|
| 2-3. |
XKBP-00030
|
[1] |
SCREW-SET
|
|
| 2-4. |
XKBP-00031
|
[1] |
PISTON
|
|
| 2-5. |
XKBP-00032
|
[1] |
SEAL-PISTON
|
|
| 2-6. |
XKBP-00033
|
[1] |
O-RING
|
|
| 2-7. |
XKBP-00034
|
[1] |
BUSH-DU
|
|
| 2-8. |
XKBP-00035
|
[1] |
O-RING
|
|
| 2-9. |
XKBP-00036
|
[1] |
SEAL-ROD
|
|
| 2-10. |
XKBP-00037
|
[1] |
O-RING
|
|
| 2-11. |
XKBP-00038
|
[1] |
COVER
|
|
| 2-12. |
XKBP-00039
|
[1] |
SEAL-DUST
|
|
| 2-13. |
XKBP-00040
|
[1] |
ROD
|
|
| 2-14. |
XKBP-00041
|
[1] |
PLUG
|
|
| 2-15. |
XKBP-00042
|
[1] |
O-RING
|
|
| 2-16. |
XKBP-00043
|
[1] |
BUSH-DU
|
|
| 3. |
XKBP-00003
|
[1] |
HOOK
|
|
| 4. |
XKBP-00004
|
[1] |
LOCK
|
|
| 5. |
XKBP-00005
|
[2] |
PIN-BRACKET
|
|
| 6. |
XKBP-00006
|
[1] |
PIN-HOOK
|
|
| 7. |
XKBP-00007
|
[1] |
PIN-JOINT
|
|
| 8. |
XKBP-00008
|
[1] |
PIN-JOINT
|
|
| 9. |
XKBP-00009
|
[1] |
PIN-LOCK
|
|
| 10. |
XKBP-00010
|
[1] |
RING-SNAP
|
|
| 11. |
XKBP-00011
|
[1] |
RING-SNAP
|
|
| 12. |
XKBP-00012
|
[2] |
RING-SNAP
|
|
| 13. |
XKBP-00013
|
[2] |
BOLT-HEX
|
|
| 14. |
XKBP-00014
|
[4] |
NUT-HEX
|
|
| 15. |
XKBP-00015
|
[5] |
NIPPLE-GREASE
|
|
| 16. |
XKBP-00016
|
[2] |
BOLT-SOCKET
|
|
| 17. |
XKBP-00017
|
[1] |
PLATE-COVER
|
|
| 18. |
XKBP-00018
|
[2] |
ELBOW-90
|
|
| 19. |
XKBP-00019
|
[2] |
O-RING
|
|
| 20. |
XKBP-00020
|
[2] |
HOSE ASSY
|
|
| 21. |
XKBP-00021
|
[1] |
SPRING
|
|
| 22. |
XKBP-00022
|
[1] |
PIN-SPRING
|
|
| 23. |
XKBP-00023
|
[1] |
STOPPER
|
|
| 24. |
XKBP-00024
|
[1] |
NIPPLE-GREASE
|
|
| 25. |
XKBP-00025
|
[1] |
PIN-STOPPER
|
|
| 25. |
XKBP-00104
|
[1] |
PIN-STOPPER
|
|
| 26. |
XKBP-00026
|
[1] |
PIN-SNAP
|
|
| 27. |
XKBP-00027
|
[1] |
WIRE ASSY
|
|
| 27. |
XKBP-00106
|
[1] |
WIRE ASSY
|
|
