现代零件查询R140W-7 QUICK CLAMP CYLINDER(#0429-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
1016 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
CYLINDER-QUICK CALMP
|
|
| 1. |
XKBN-00117
|
[1] |
TUBE
|
|
| 2. |
XKBN-00118
|
[1] |
ROD
|
|
| 3. |
XKBN-00119
|
[1] |
COVER-ROD
|
|
| 4. |
XKBN-00120
|
[1] |
WIPER-DUST
|
|
| N5. |
XKBN-00568
|
[1] |
U-PACKING
|
|
| 6. |
XKBN-00122
|
[1] |
RING-BACK UP
|
|
| 7. |
XKBN-00123
|
[1] |
BUSH-DU
|
|
| 8. |
XKBN-00124
|
[1] |
O-RING
|
|
| 9. |
XKBN-00125
|
[1] |
RING-BACK UP
|
|
| 11. |
XKBN-00126
|
[1] |
PISTON
|
|
| 12. |
XKBN-00127
|
[1] |
O-RING
|
|
| 13. |
XKBN-00128
|
[1] |
SEAL-COMPACT
|
|
| N14. |
XKBN-00129
|
[1] |
NUT-TEFRON
|
|
| 15. |
XKBN-00130
|
[1] |
PIN-SPRING
|
|
| 16. |
XKBN-00131
|
[1] |
CHECK VALVE-PILOT
|
|
| 17. |
XKBN-00132
|
[2] |
BOLT-HEX,PLUG
|
|
