现代零件查询R140W-7 PILOT HYD PIPING(BASE 1, #0199-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
333 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
PILOT HYD PIPING
|
|
| 10. |
P910-043044
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 11. |
P910-043049
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 22. |
X410-042008
|
[1] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 31. |
S621-011001
|
[18] |
O-RING,ORFS
|
|
| 48. |
X820-045151
|
[2] |
TEE-R/TYPE,ORFS
|
|
| 51. |
X500-110001
|
[3] |
CONNECTOR-ORFS
|
|
| 55. |
X520-110001
|
[4] |
ELBOW-90,ORFS
|
|
| 58. |
X520-110012
|
[2] |
ELBOW-90,ORFS
|
|
| 62. |
X710-100102
|
[1] |
CAP-ORFS
|
|
| 67. |
S631-011004
|
[9] |
O-RING
|
|
| 68. |
S631-014004
|
[2] |
O-RING
|
|
| 78. |
X400-042017
|
[1] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 79. |
X400-042020
|
[1] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 85. |
X420-042009
|
[3] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 86. |
X420-042018
|
[1] |
HOSE ASSY-SYNFLEX,ORFS
|
|
