纽荷兰零件查询(F4HFE613Y A005) - ENGINE 5801425075 - 84387923 (10.101.03) - BREATHER - ENGINE (4897637) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
346 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4897534 | [1] | TUBE | TOR |
| 2. | 4897546 | [1] | RUBBER SLEEVE | TORIN ALTERNATIVE Superseded by part number: 2854521 |
| 3. | 4897547 | [1] | TUBE | TOR |
| 4. | 4897537 | [1] | SCREW | TORM6X1X10 |
| 5. | 4897536 | [1] | BRACKET | TOR |
| 6. | 4899219 | [1] | TUBE | TOR- ASSY |
| 7. | 4898439 | [1] | O-RING,20.29mm ID x 2.62mm Width | TOR Superseded by part number: 17282081 |
| 8. | 4899092 | [3] | SCREW,Hex Flg, M6 x 1 x 25 | TOR |
| 9. | 4892871 | [1] | BREATHER | TOR- ASSY |
| 10. | 4893234 | [2] | HOSE CLAMP | TORIN ALTERNATIVE |
