现代零件查询R140W-7 POWER TRAIN HYD PIPING 2(#0560-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
603 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
POWER TRAIN PIPING
|
|
| 5. |
31EA-30150
|
[1] |
BRAKE SUPPLY VALVE
|
|
| 6. |
81L1-0003
|
[2] |
ACCUMULATOR
|
|
| 7. |
31EC-02190
|
[1] |
ACCUMULATOR
|
|
| 10. |
31LF-00500
|
[1] |
SWITCH-PRESSURE
|
|
| 13. |
31EK-11130
|
[5] |
COUPLING-SCREW
|
|
| 15. |
31N6-30120
|
[1] |
CONNECTOR
|
|
| 15. |
31Q6-30160
|
[1] |
CONNECTOR-LONG
|
|
| 18. |
31N6-30110
|
[2] |
CONNECTOR
|
|
| 20. |
X500-110001
|
[1] |
CONNECTOR-ORFS
|
|
| 22. |
X511-106513
|
[1] |
CONNECTOR-LONG,ORFS
|
|
| 31. |
X520-110003
|
[1] |
ELBOW-90,ORFS
|
|
| 33. |
31N4-22310
|
[2] |
TEE-RUN TYPE/TEST
|
|
| 36. |
P220-110102
|
[3] |
PLUG-HEX
|
|
| 38. |
P220-110104
|
[1] |
PLUG-HEX
|
|
| 42. |
S017-100902
|
[3] |
BOLT-HEX
|
|
| 49. |
S205-101002
|
[3] |
NUT-HEX
|
|
| 50. |
S403-102002
|
[6] |
WASHER-PLAIN
|
|
| 51. |
S411-100002
|
[6] |
WASHER-SPRING
|
|
| 52. |
S621-021001
|
[2] |
O-RING
|
|
| 53. |
X420-062056
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 54. |
P930-082013
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 55. |
S621-014001
|
[4] |
O-RING
|
|
| 56. |
S631-011004
|
[8] |
O-RING
|
|
| 57. |
S631-014004
|
[5] |
O-RING
|
|
| 58. |
S631-018004
|
[4] |
O-RING
|
|
| 58. |
S631-018004
|
[3] |
O-RING
|
|
| 61. |
S551-050203
|
[2] |
CLAMP-BAND
|
|
| 66. |
P930-082023
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 68. |
X410-062046
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 70. |
X420-042044
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 71. |
X420-042045
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 72. |
X420-042076
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 73. |
P930-066050
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 79. |
S621-011001
|
[3] |
O-RING
|
|
| 80. |
S621-012001
|
[6] |
O-RING
|
|
| 86. |
31E3-3187
|
[1] |
ACCUMULATOR
|
|
