现代零件查询R140W-7 LOWER HYD PIPING 1(-#0559)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
826 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 3. |
81E3-0014
|
[1] |
VALVE-LOCKING
|
|
| 4. |
31N4-44010
|
[2] |
BLOCK
|
|
| 7. |
31N8-12521
|
[2] |
ELBOW-ORFS
|
|
| 8. |
P923-127021
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 8. |
P920-127021
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 9. |
P923-127022
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 9. |
P920-127022
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 10. |
P933-122021
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 10. |
P933-122022
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 10. |
P930-122022
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 11. |
P933-082023
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 11. |
P930-082023
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 18. |
P603-062019
|
[1] |
HOSE ASSY-THD
|
|
| 18. |
P913-062019
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 19. |
P613-042026
|
[1] |
HOSE ASSY-THD 0X45
|
|
| 19. |
P923-042026
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 20. |
P613-062009
|
[1] |
HOSE ASSY-THD 0X45
|
|
| 20. |
P923-062009
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 21. |
P613-062011
|
[1] |
HOSE ASSY-THD 0X45
|
|
| 21. |
P923-062011
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 22. |
P623-042012
|
[1] |
HOSE ASSY-THD 0X90
|
|
| 22. |
P933-042012
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 23. |
P010-110002
|
[1] |
CONNECTOR
|
|
| 23. |
X500-110001
|
[1] |
CONNECTOR-ORFS
|
|
| 25. |
P010-110013
|
[1] |
CONNECTOR
|
|
| 25. |
X500-110013
|
[1] |
CONNECTOR-ORFS
|
|
| 26. |
P010-210002
|
[1] |
CONNECTOR
|
|
| 26. |
X500-210002
|
[1] |
CONNECTOR-ORFS
|
|
| 27. |
P010-210005
|
[2] |
CONNECTOR
|
|
| 27. |
X500-210005
|
[2] |
CONNECTOR-ORFS
|
|
| 29. |
X500-110003
|
[1] |
CONNECTOR-ORFS
|
|
| 30. |
X500-110004
|
[1] |
CONNECTOR-ORFS
|
|
| 31. |
31N4-41080
|
[1] |
CONNECTOR-ORFS
|
|
| 32. |
X500-220007
|
[1] |
CONNECTOR-ORFS
|
|
| 33. |
P020-110001
|
[1] |
ELBOW-90
|
|
| 33. |
X520-110001
|
[1] |
ELBOW-90,ORFS
|
|
| 34. |
P020-110002
|
[2] |
ELBOW-90
|
|
| 34. |
X520-110002
|
[2] |
ELBOW-90,ORFS
|
|
| 34. |
X520-110002
|
[3] |
ELBOW-90,ORFS
|
|
| 37. |
X520-110004
|
[2] |
ELBOW-90,ORFS
|
|
| 38. |
P030-110002
|
[1] |
ELBOW-45
|
|
| 38. |
X530-110002
|
[1] |
ELBOW-45,ORFS
|
|
| 41. |
31M6-51160
|
[1] |
TEE-R/TYPE,S/NUT
|
|
| 41. |
31N4-41140
|
[1] |
TEE-S/NUT,ORFS
|
|
| 44. |
31E4-3146
|
[2] |
STRAP
|
|
| 46. |
P392-180000
|
[1] |
WASHER-COPPER
|
|
| 47. |
P392-270000
|
[1] |
WASHER-COPPER
|
|
| 48. |
S015-080802
|
[2] |
BOLT-HEX
|
|
| 50. |
S017-160502
|
[4] |
BOLT-HEX
|
|
| 51. |
S035-081512
|
[4] |
BOLT-W/WASHER
|
|
| 53. |
S109-100306
|
[8] |
BOLT-SOCKET
|
|
| 54. |
S109-120356
|
[2] |
BOLT-SOCKET
|
|
| 55. |
S109-120956
|
[6] |
BOLT-SOCKET
|
|
| 57. |
S411-080006
|
[2] |
WASHER-SPRING
|
|
| 59. |
S411-160006
|
[4] |
WASHER-SPRING
|
|
| 60. |
S621-014001
|
[2] |
O-RING(SEAL LOCK TYPE)
|
|
| 61. |
S621-018001
|
[6] |
O-RING(SEAL LOCK TYPE)
|
|
| 62. |
S631-011004
|
[2] |
O-RING
|
|
| 63. |
S631-014004
|
[4] |
O-RING
|
|
| 64. |
S631-018004
|
[1] |
O-RING
|
|
| 65. |
S631-024004
|
[3] |
O-RING
|
|
| 66. |
Y161-014001
|
[1] |
O-RING
|
|
| 67. |
Y161-016001
|
[2] |
O-RING
|
|
| 69. |
Y171-019004
|
[2] |
O-RING
|
|
| 70. |
Y171-024004
|
[2] |
O-RING
|
|
| 71. |
S552-102370
|
[10] |
CLAMP-BAND
|
|
| 72. |
P173-120102
|
[4] |
FLANGE-HYD,SPLIT
|
|
| 74. |
S621-011001
|
[4] |
O-RING(SEAL LOCK TYPE)
|
|
| 75. |
S621-012001
|
[6] |
O-RING(SEAL LOCK TYPE)
|
|
