现代零件查询R140W-7 LOWER HYD PIPING 2(-#0559)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
756 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
31N4-41061
|
[1] |
PIPE ASSY
|
|
| 6. |
31N4-41071
|
[1] |
PIPE ASSY
|
|
| 12. |
P613-067007
|
[2] |
HOSE ASSY-THD 0X45
|
|
| 12. |
P923-067007
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 13. |
P613-066034
|
[2] |
HOSE ASSY-THD 0X45
|
|
| 13. |
P923-066034
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 13. |
P933-066034
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 13. |
P923-066032
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 14. |
P623-066029
|
[1] |
HOSE ASSY-THD 0X90
|
|
| 14. |
P933-066029
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 15. |
P623-066030
|
[1] |
HOSE ASSY-THD 0X90
|
|
| 15. |
P933-066030
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 16. |
P623-042009
|
[2] |
HOSE ASSY-THD 0X90
|
|
| 16. |
P933-042009
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 17. |
P613-042017
|
[2] |
HOSE ASSY-THD 0X45
|
|
| 17. |
P923-042017
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 17. |
P923-042015
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 24. |
P010-110003
|
[4] |
CONNECTOR
|
|
| 24. |
X500-110002
|
[4] |
CONNECTOR-ORFS
|
|
| 24. |
X500-110002
|
[6] |
CONNECTOR-ORFS
|
|
| 26. |
P010-210002
|
[2] |
CONNECTOR
|
|
| 26. |
X500-210002
|
[2] |
CONNECTOR-ORFS
|
|
| 28. |
31N4-41050
|
[2] |
CONNECTOR
|
|
| 28. |
31N4-41130
|
[2] |
CONNECTOR-ORFS
|
|
| 35. |
31E3-3175
|
[2] |
ELBOW-90
|
|
| 36. |
34EA-40150
|
[2] |
ELBOW
|
|
| 36. |
31N4-41150
|
[2] |
ELBOW-90,ORFS
|
|
| 36. |
X500-220006
|
[2] |
CONNECTOR-ORFS
|
|
| 38. |
P030-110002
|
[2] |
ELBOW-45
|
|
| 38. |
X530-110002
|
[2] |
ELBOW-45,ORFS
|
|
| 39. |
P010-210002
|
[2] |
CONNECTOR
|
|
| 40. |
31EM-45430
|
[2] |
TEE-BRAKE
|
|
| 40. |
31N5-41030
|
[2] |
TEE-MTG
|
|
| 42. |
31E4-3095
|
[1] |
STRAP
|
|
| 43. |
31E4-3097
|
[2] |
STRAP
|
|
| 49. |
S017-120452
|
[4] |
BOLT-HEXAGON HEAD
|
|
| 51. |
S035-081512
|
[6] |
BOLT-W/WASHER
|
|
| 52. |
S037-103542
|
[2] |
BOLT-W/WASHER
|
|
| 56. |
S207-121002
|
[4] |
NUT-HEXAGON HEAD
|
|
| 58. |
S411-120006
|
[4] |
WASHER-SPRING
|
|
| 63. |
S631-014004
|
[8] |
O-RING
|
|
| 66. |
Y161-014001
|
[4] |
O-RING
|
|
| 68. |
Y161-018001
|
[2] |
O-RING
|
|
| 68. |
P392-180000
|
[2] |
WASHER-COPPER
|
|
| 71. |
S552-102370
|
[10] |
CLAMP-BAND
|
|
| 73. |
S403-121002
|
[4] |
WASHER-PLAIN
|
|
| 74. |
S621-011001
|
[8] |
O-RING(SEAL LOCK TYPE)
|
|
| 75. |
S621-012001
|
[10] |
O-RING(SEAL LOCK TYPE)
|
|
