现代零件查询R140W-7 LOWER HYD PIPING 2(#0560-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
141 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
LOWER PIPING INSTALL
|
|
| 5. |
31N4-41260
|
[1] |
PIPE ASSY
|
|
| 6. |
31N4-41270
|
[1] |
PIPE ASSY
|
|
| 11. |
P923-067007
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 12. |
P923-066032
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 13. |
P933-066029
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 14. |
P933-066030
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 15. |
P933-042009
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 16. |
P923-042015
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 22. |
X500-110002
|
[6] |
CONNECTOR-ORFS
|
|
| 24. |
X500-210002
|
[4] |
CONNECTOR-ORFS
|
|
| 26. |
31E3-3113
|
[2] |
CONNECTOR
|
|
| 33. |
31E3-3175
|
[2] |
ELBOW-90
|
|
| 34. |
X500-220006
|
[2] |
CONNECTOR-ORFS
|
|
| 36. |
31N5-41030
|
[2] |
TEE-MTG
|
|
| 37. |
31E4-3095
|
[1] |
STRAP
|
|
| 43. |
S017-120456
|
[4] |
BOLT-HEX
|
|
| 45. |
S035-081516
|
[10] |
BOLT-W/WASHER
|
|
| 46. |
S037-103546
|
[2] |
BOLT-W/WASHER
|
|
| 49. |
S109-120956
|
[6] |
BOLT-SOCKET
|
|
| 50. |
S207-121006
|
[4] |
NUT-HEX
|
|
| 52. |
S411-120006
|
[4] |
WASHER-SPRING
|
|
| 57. |
S631-014004
|
[9] |
O-RING
|
|
| 60. |
Y161-014001
|
[4] |
O-RING
|
|
| 62. |
P392-180000
|
[2] |
WASHER-COPPER
|
|
| 67. |
S403-12100B
|
[4] |
WASHER-PLAIN
|
|
| 68. |
S621-011001
|
[8] |
O-RING
|
|
| 69. |
S621-012001
|
[10] |
O-RING
|
|
