现代零件查询R140W-7 LOWER HYD PIPING(REAR BLADE)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
578 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 3. |
34EA-10250
|
[2] |
CLAMP-PIPE
|
|
| 4. |
31N5-70111
|
[1] |
PIPE ASSY
|
|
| 5. |
31N5-70121
|
[1] |
PIPE ASSY
|
|
| 6. |
P913-087011
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 7. |
P603-067024
|
[4] |
HOSE ASSY-THD
|
|
| 7. |
P913-067024
|
[4] |
HOSE ASSY-ORFS 0X0
|
|
| 8. |
P603-047018
|
[1] |
HOSE ASSY-THD
|
|
| 8. |
P913-047018
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P010-110003
|
[4] |
CONNECTOR
|
|
| 9. |
X500-110002
|
[4] |
CONNECTOR-ORFS
|
|
| 10. |
P020-110001
|
[2] |
ELBOW-90
|
|
| 10. |
X520-110001
|
[2] |
ELBOW-90,ORFS
|
|
| 11. |
P220-110102
|
[2] |
PLUG-HEX
|
|
| 12. |
P220-110103
|
[1] |
PLUG-HEX
|
|
| 13. |
P220-110104
|
[1] |
PLUG-HEX
|
|
| 14. |
X500-110003
|
[2] |
CONNECTOR-ORFS
|
|
| 15. |
X710-100104
|
[4] |
CAP-HYD,ORFS
|
|
| 16. |
S017-100606
|
[2] |
BOLT-HEX
|
|
| 17. |
S621-014001
|
[8] |
O-RING
|
|
| 18. |
S631-011004
|
[4] |
O-RING
|
|
| 19. |
S631-014004
|
[5] |
O-RING
|
|
| 20. |
S631-018004
|
[3] |
O-RING
|
|
| 21. |
S403-10100B
|
[2] |
WASHER-PLAIN
|
|
| 22. |
S411-100006
|
[2] |
WASHER-SPRING
|
|
| 23. |
S552-102370
|
[10] |
CLAMP-BAND
|
|
| 24. |
S760-100800
|
[4] |
GROMMET
|
|
| 25. |
S621-011001
|
[2] |
O-RING
|
|
| 26. |
S621-012001
|
[8] |
O-RING
|
|
