现代零件查询R140W-7 ARM SAFETY LOCK SYSTEMEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
170 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
31N4-52130
|
[1] |
ARM SAFE LOCK CYL
|
|
| 1. |
31N4-52132
|
[1] |
ARM SAFE LOCK CYL
|
|
| 1-0. |
@
|
[1] |
ARM CYL SUB ASSY
|
|
| 1-1. |
31N6-90510
|
[1] |
VALVE-SAFETY LOCK
|
|
| 1-1-1. |
ZTAS-00001
|
[1] |
VALVE-RELIEF
|
|
| 1-1-2. |
ZTAS-00002
|
[1] |
CAP
|
|
| 1-1-3. |
ZTAS-00004
|
[1] |
SEAL KIT
|
|
| 1-2. |
31Y1-18540
|
[1] |
PIPE ASSY-RV
|
|
| 1-3. |
P184-121112
|
[1] |
FLANGE-HYD,PLUGING
|
|
| K1-4. |
Y171-019001
|
[3] |
O-RING
|
|
| 1-5. |
S109-100356
|
[4] |
BOLT-SOCKET
|
|
| 1-6. |
S109-100456
|
[4] |
BOLT-SOCKET
|
|
| 1-7. |
S109-100506
|
[4] |
BOLT-SOCKET
|
|
| 2. |
P420-042122
|
[1] |
HOSE ASSY-COMP 0X90
|
|
| 2. |
P600-042083
|
[1] |
HOSE ASSY-THD 0X0
|
|
| 2. |
P910-042083
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
P930-042083
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 2. |
P420-042113
|
[1] |
HOSE ASSY-COMP 0X90
|
|
| 2. |
P600-042074
|
[1] |
HOSE ASSY-THD 0X0
|
|
| 2. |
P910-042074
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
P930-042078
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 2. |
P420-042132
|
[1] |
HOSE ASSY-COMP 0X90
|
|
| 2. |
P600-042093
|
[1] |
HOSE ASSY-THD 0X0
|
|
| 2. |
P910-042093
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 2. |
P930-042097
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 3. |
P420-062125
|
[1] |
HOSE ASSY-COMP 0X90
|
|
| 3. |
P600-062083
|
[1] |
HOSE ASSY-THD 0X0
|
|
| 3. |
P910-062083
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
P930-062083
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 3. |
P420-062116
|
[1] |
HOSE ASSY-COMP 0X90
|
|
| 3. |
P600-062074
|
[1] |
HOSE ASSY-THD 0X0
|
|
| 3. |
P910-062074
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
P930-062078
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 3. |
P420-062134
|
[1] |
HOSE ASSY-COMP 0X90
|
|
| 3. |
P600-062093
|
[1] |
HOSE ASSY-THD 0X0
|
|
| 3. |
P910-062093
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 3. |
P930-062097
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 4. |
E131-0603
|
[1] |
ELBOW-90,LONG
|
|
| 4. |
31N6-25110
|
[1] |
ELBOW-90,LONG
|
|
| 4. |
X511-104513
|
[1] |
CONNECTOR-LONG,ORFS
|
|
| 5. |
P010-110012
|
[1] |
CONNECTOR
|
|
| 5. |
P020-110012
|
[1] |
ELBOW-90
|
|
| 5. |
X520-110011
|
[1] |
ELBOW-90,ORFS
|
|
| 5. |
X500-110011
|
[1] |
CONNECTOR-ORFS
|
|
| 6. |
31E6-0219
|
[1] |
TEE-LONG
|
|
| 6. |
31N4-22150
|
[1] |
TEE-LONG,ORFS
|
|
| 7. |
P220-110102
|
[1] |
PLUG-HEX
|
|
| 8. |
S631-014001
|
[3] |
O-RING
|
|
| 8. |
S631-014001
|
[4] |
O-RING
|
|
| 9. |
S552-020102
|
[10] |
CLAMP-BAND
|
|
| 10. |
P620-042039
|
[1] |
HOSE ASSY-THD 0X90
|
|
| 10. |
P930-042039
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 11. |
P600-062042
|
[1] |
HOSE ASSY-THD 0X0
|
|
| 11. |
P910-062042
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 12. |
31L7-40190
|
[1] |
CONNECTOR
|
|
| 12. |
X540-110001
|
[1] |
CONNECTOR-ORFS
|
|
| 13. |
31L7-40180
|
[1] |
CONNECTOR
|
|
| 13. |
X540-110002
|
[1] |
CONNECTOR-ORFS
|
|
| 14. |
S621-011001
|
[4] |
O-RING
|
|
| 15. |
S621-012001
|
[4] |
O-RING
|
|
| K. |
31Y1-18590
|
[1] |
SEAL KIT
|
|
