现代零件查询R140W-7 DOUBLE ACTING ATTACH PIPING KIT(-#0036)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
262 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
D/ACT ATTACH PIPING KIT
|
|
| -12. |
31N4-91310
|
[1] |
ATTACH PIPING KIT
|
|
| -12. |
31N4-91320
|
[1] |
ATTACH PIPING KIT
|
|
| -12. |
31N4-91330
|
[1] |
ATTACH PIPING KIT
|
|
| -12. |
31N4-91340
|
[1] |
ATTACH PIPING KIT
|
|
| 1. |
31N4-92110
|
[2] |
PIPE ASSY
|
|
| 1. |
31N4-92120
|
[2] |
PIPE ASSY
|
|
| 1. |
31N4-92140
|
[2] |
PIPE ASSY
|
|
| 2. |
31N4-92151
|
[2] |
PIPE ASSY
|
|
| 3. |
31N4-92170
|
[2] |
PIPE ASSY
|
|
| 4. |
P913-126026
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 5. |
P913-126027
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 6. |
32E6-92110
|
[2] |
VALVE-STOP
|
|
| 7. |
X530-110004
|
[2] |
ELBOW-45,ORFS
|
|
| 8. |
31EG-91350
|
[2] |
CLAMP-STOP VALVE
|
|
| 9. |
31EG-91381
|
[4] |
CLAMP-PIPE
|
|
| 10. |
31N4-12200
|
[4] |
CLAMP-PIPE
|
|
| 11. |
S631-024001
|
[2] |
O-RING
|
|
| 12. |
S621-018001
|
[10] |
O-RING
|
|
| 13. |
S017-120702
|
[6] |
BOLT-HEXAGON HEAD
|
|
| 14. |
S017-160702
|
[2] |
BOLT-HEX
|
|
| 15. |
S401-120002
|
[4] |
WASHER-PLAIN
|
|
| 16. |
S411-120002
|
[4] |
WASHER-SPRING
|
|
| 17. |
S411-160002
|
[2] |
WASHER-SPRING
|
|
| 27. |
X710-100105
|
[2] |
CAP-DUST
|
|
| -2. |
31E6-91701
|
[1] |
ACCUMULATOR KIT
|
|
| 18. |
32E6-92040
|
[1] |
ACCUMULATOR
|
|
| 19. |
32E6-92050
|
[1] |
ACCUMULATOR
|
|
| 20. |
32E3-2021
|
[1] |
FITTING
|
|
| 21. |
32E3-2020
|
[1] |
FITTING
|
|
| 22. |
P392-220000
|
[1] |
WASHER-COPPER
|
|
| 23. |
P392-180000
|
[1] |
WASHER-COPPER
|
|
| 24. |
32E6-92060
|
[2] |
U-BOLT
|
|
| 25. |
S071-032730
|
[4] |
U-BOLT
|
|
| 26. |
32E6-92080
|
[2] |
BRACKET-ACCUM
|
|
