现代零件查询R140W-7 DOUBLE ACTING ATTACH PIPING KIT(#0037-)EPC Hyundai _现代Hyundai_工程机械

现代零件查询R140W-7 DOUBLE ACTING ATTACH PIPING KIT(#0037-)EPC Hyundai

广数供应链运营团队, 14 02月, 2025，浏览： 934 次

Pos.	Part No	Qty	Parts name	Comments
.	@	[1]	D/ACT ATTACH PIPING KIT
-12.	31N4-95331	[1]	ATTACH PIPING KIT	4.6BM+2.1AM
-12.	31N4-95341	[1]	ATTACH PIPING KIT	4.6BM+1.9AM
-12.	31N4-95351	[1]	ATTACH PIPING KIT	4.6BM+2.5AM
-12.	31N4-95361	[1]	ATTACH PIPING KIT	4.6BM+3.0AM
1.	31N4-92231	[2]	PIPE ASSY	2.1AM
1.	31N4-92221	[2]	PIPE ASSY	1.9AM
1.	31N4-92211	[2]	PIPE ASSY	2.5AM
1.	31N4-92241	[2]	PIPE ASSY	3.0AM
2.	31N4-92250	[1]	PIPE ASSY
3.	31N4-92260	[1]	PIPE ASSY
4.	31N4-95601	[1]	PIPE ASSY
5.	31N4-95630	[1]	PIPE ASSY
6.	P933-126034	[2]	HOSE ASSY-ORFS 0X90	2.5AM, 3.0AM
6.	P933-126028	[2]	HOSE ASSY-ORFS 0X90	1.9AM, 2.1AM
7.	X710-100105	[2]	CAP-DUST
8.	31N4-97010	[2]	VALVE-STOP
9.	X530-110004	[2]	ELBOW-45,ORFS
10.	31EG-91350	[2]	CLAMP-STOP VALVE
11.	31EG-91381	[4]	CLAMP-PIPE	2.5AM ONLY
11.	31EG-91381	[2]	CLAMP-PIPE	1.9AM, 2.1AM
11.	31EG-91381	[6]	CLAMP-PIPE	3.0AM ONLY
12.	32E6-92160	[2]	BRACKET	3.0AM ONLY
13.	P220-110205	[2]	PLUG-SOCKET
14.	31EK-11130	[2]	COUPLING-SCREW
15.	S631-011004	[2]	O-RING
16.	S631-024004	[6]	O-RING
17.	S621-018001	[8]	O-RING
18.	Y171-019004	[2]	O-RING
19.	S017-120256	[4]	BOLT-HEX	3.0AM ONLY
20.	S017-120506	[8]	BOLT-HEX	2.5AM ONLY
20.	S017-120506	[4]	BOLT-HEX	1.9AM, 2.1AM
20.	S017-120506	[12]	BOLT-HEX	3.0AM ONLY
21.	S017-120706	[4]	BOLT-HEX
22.	S109-100506	[8]	BOLT-SOCKET
23.	S411-120002	[12]	WASHER-SPRING	2.5AM ONLY
23.	S411-120002	[8]	WASHER-SPRING	1.9AM, 2.1AM
23.	S411-120002	[20]	WASHER-SPRING	3.0AM ONLY
-2.	31E6-91701	[1]	ACCUMULATOR KIT
24.	32E6-92040	[1]	ACCUMULATOR
25.	32E6-92050	[1]	ACCUMULATOR
26.	32E3-2021	[1]	FITTING
27.	32E3-2020	[1]	FITTING
28.	P392-220000	[1]	WASHER-COPPER
29.	P392-180000	[1]	WASHER-COPPER
30.	32E6-92060	[2]	U-BOLT
31.	S071-032730	[4]	U-BOLT
32.	32E6-92080	[2]	BRACKET-ACCUM
