纽荷兰零件查询(F5CE5454B A005) - ENGINE 504387947 - 84230116 (10.105.AG) - PISTON ASSEMBLY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
586 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8097546 | [4] | PISTON ASSY | TORStd Superseded by part number: 8097915 |
| 1. | 8097548 | [4] | PISTON ASSY +0.4 | TOR Superseded by part number: 8097916 |
| 2. | 504051611 | [8] | LOCK WASHER | TOR |
| 3. | 504047720 | [4] | PISTON PIN | TOR |
| 4. | 8097545 | [4] | PISTON RING SET | TORStd |
| 4. | 8097547 | [4] | SET OF PISTON RINGS +0.4 | TOR |
| 5. | NSS | [4] | NOT SERVICED SEPARATELY | CONPiston, Incl in 1 |
